| Categories | 16x2 LCD |
|---|---|
| Supply Ability: | 5000000000 pieces/year |
| Display Type: | Alphanumeric LCD Display |
| Controller: | ST7066U or AIP31066 |
| Product Name: | Alphanumeric LCD 16x2 Display STN 1602 LCD Screen |
| MOQ: | 1 piece |
| Dimensions: | 80.0mm * 36.0mm * 12.5mm |
| Brand Name: | Formike |
| Display format: | 16character*2 line |
| Backlight: | LED |
| Display Mode: | STN |
| Interface: | 18 Pin, 4-bit or 8-bit 6800 MPU |
| Viewing Angle: | 6 O'clock |
| Operating Voltage: | 3.3V / 5V |
| Packaging Details: | Tray + Inner Box + Carton |
| Backlight Color: | Usually Y-G or Blue or Gray or VA Black |
| Model Number: | WC1602B7 |
| Place of Origin: | China |
| Payment Terms: | T/T,L/C,Credit card,Cash |
| Delivery Time: | In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks; |
| Operating Temperature: | -20°C to 70°C |
| Company Info. |
| Formike Electronic Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Product Specification | ||||||
|---|---|---|---|---|---|---|
| LCD Name | Alphanumeric LCD 16x2 Display STN 1602 LCD Screen | |||||
| Display Format | 16character*2 line | |||||
| Module Size | 80.0mm×36.0mm×12.5mm | |||||
| View Area | 64.5mm×16.0mm | |||||
| Character Size | 2.96mm×5.53mm | |||||
| Character Pitch | 3.55mm×5.98mm | |||||
| IC | AIP31066 or Eqv (Defualt English / Japan Font) | |||||
| Interface | 18 Pin, 4-bit or 8-bit 6800 MPU interface enabled | |||||
| Driving Method | 1/16 Duty, 1/5 Bias | |||||
| Viewing Direction | 6 O’clock | |||||
| Operating Temperature | -20℃~+70℃ | |||||
| Storage Temperature | -30℃~+80℃ | |||||
| Different series type LCD mode for you to choose | ||||||
| No. | Part Number | LCD Type | Backlight Color | Font Color | Background Color | Voltage |
| 1 | WC1602B7VVE6B-A1 | VA Black negative | RGB Color | RGB Color | Black Color | 5V |
| 2 | WC1602B7VVE6B-A2 | VA Black negative | RGB Color | RGB Color | Black Color | 3.3V |
| 3 | WC1602B7SKE6B-A1 | STN Positive Gray | RGB Color | Black Color | RGB Color | 5V |
| 4 | WC1602B7SKE6B-A2 | STN Positive Gray | RGB Color | Black Color | RGB Color | 3.3V |
|
