Keyence FS-N41P Digital Fiber Optic Sensor Amplifier

Categories Keyence Sensors
Model Number: FS-N41P
Supply Ability: 100PC
Head Mount: DIN form B head mount
Special Features: Integrated TwinCAT 3 runtime environment
Packaging Details: carton
Operating Temperature: -25°C to +60°C
Brand Name: KEYENCE
Indicator: Power indicator
Price: negotiate
Measuring Range: 150 mm
Product No: BSW000R
Payment Terms: T/T,Alipay,Paypal,XT
Temperature Range: -25°C To +60°C
Place of Origin: China
MOQ: 1
Line Voltage: 200 to 600 Volts AC
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Keyence FS-N41P Digital Fiber Optic Sensor Amplifier

Keyence FS-N41P Digital Fiber Optic Sensor Amplifier


Manufacturer :KEYENCE
Product No. : FS-N41P

ParameterSpecification
Model NumberFS-N41P
BrandKeyence
SeriesFS-N Digital Fiber Optic Amplifier Series
Unit TypeCable Type, Main Unit
Output TypePNP Open Collector
Number of Control Output1 channel
Light SourceRed four-element LED, 660 nm
Response Speed Modes23 µs (S-HSPD) / 50 µs (HSPD) / 250 µs (FINE) / 500 µs (TURBO) / 1 ms (SUPER) / 4 ms (ULTRA) / 16 ms (MEGA) / 64 ms (TERA)
Supply Voltage10 VDC ~ 30 VDC (ripple ≤10% P-P)
Max Output Load Current≤100 mA
Residual Output Voltage≤2.2 V (10–100 mA)
Power ConsumptionNormal: ≤910 mW; ECO ON: ≤840 mW; ECO FULL: ≤750 mW
Anti-interference CapacityUp to 8 units side-by-side (TURBO mode)
Protection FunctionsReverse polarity, overcurrent, surge protection


ParameterSpecification
Housing MaterialPolycarbonate
Mounting MethodStandard DIN rail mounting
Ambient Operating Temperature-20 °C ~ +55 °C (non-freezing)
Storage Temperature-25 °C ~ +70 °C
Allowable Ambient LightIncandescent lamp ≤20,000 lux, Sunlight ≤30,000 lux
Vibration Resistance10–55 Hz, 1.5 mm double amplitude, 2 hours on X/Y/Z axis
Shock Resistance500 m/s², 3 shocks for each X/Y/Z axis
Cable SpecificationIntegrated 2 m cable
Protection ClassIP40 (amplifier body)
ApprovalsUL, CSA, CE
ComplianceRoHS
