| Categories | PVC Power Cable |
|---|---|
| Place of Origin: | Shandong, China |
| Brand Name: | jinyu |
| Model Number: | BVV |
| Type: | construction cable |
| Application: | electric wire |
| Conductor Material: | Copper |
| Conductor Type: | Stranded |
| Insulation Material: | PVC |
| Product name: | construction cable |
| Keyword: | power cable |
| MOQ: | 100 Metres |
| Packing: | Standard Packing |
| Delivery time: | 7-15 Days |
| Conductor: | Copper |
| Shape: | Round |
| Sample: | Acceptable |
| Advantage: | 15 Years Production Experience |
| Colors: | Red\blue\white \ Yellow \green\brown\black\grey \transparent\OEM |
| Port: | Qingdao part,Tianjin part |
| Supply Ability: | 50000000 Meter/Meters per Month |
| MOQ: | 100 meters |
| Price: | $0.50/meters >=100 meters |
| Company Info. |
| Shandong Jinyu Cable Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |


Section Nominal mm | Number/diameter of core mm | Average dia mm | Reference weight kg/km | Conductor resistance at 20 ℃ Ω/km | ||
Min | Max | |||||
2*2.5 | 1/1.78 | 8.6 | 11.5 | 154.8 | 7.41 | |
7/0.68 | 9.0 | 12.0 | 171.2 | 7.41 | ||
3*2.5 | 1/1.78 | 9.2 | 12.0 | 194.7 | 7.41 | |
7/0.68 | 9.4 | 12.5 | 215.9 | 7.41 | ||
4*2.5 | 7/0.52 | 9.0 | 12.0 | 190.7 | 12.1 | |
1/1.78 | 10.0 | 13.0 | 242.0 | 7.41 | ||
5*2.5 | 1/1.78 | 11.0 | 14.0 | 278.0 | 7.41 | |
7/0.68 | 11.0 | 14.5 | 306.9 | 7.41 | ||








|
