| Categories | PDA POS TFT LCD |
|---|---|
| Brand Name: | Jingtai |
| Place of Origin: | ShenZhen / China |
| MOQ: | 5pcs |
| Payment Terms: | T/T,Western Union,L/C,MoneyGram,D/P,D/A |
| Delivery Time: | 1-5 weeks |
| Model Number: | JT-4.95IPSINCELL |
| Certification: | ISO9001 / ISO14000 |
| Supply Ability: | 2000K pcs per month |
| Packaging Details: | Standard Exportation Package |
| Price: | 1-20 |
| Key Words: | 4.95 Inch IPS TFT LCD Display Incell |
| Resolution: | 540*960 |
| Display Mode: | IPS Full Viewing Angle |
| Aspect Ratio: | 16:9 |
| Luminance: | 250cd/m²(Typ) 500cd/m²(Typ) |
| Interface Definition: | MIPI |
| Touch Screen: | CTP |
| CTP Interface: | 12C/SPI |
| Company Info. |
| Shenzhen Jingtai Liquid Crystal Display Technology Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Application | POS/PDA |
|---|---|
| Number of pixels | 540*960 pixels |
| Active Area | 61.64*109.58mm |
| Module Outline | 64.04*114.98*2.0mm |
| Aspect Ratio | 16:9 |
| Display Mode | Normally Black |
| Viewing Angle (CR>10) | 85/85/85/85 (Typ) |
| Contrast Ratio | 1000MIN, 1500 (Typ) |
| NTSC | 70% (Typ) |
| LCM Brightness | 250cd/m² (Typ) 500cd/m² (Typ) |
| Interface | MIPI |
| Operating Temperature | -20~+70℃ |
| Storage Temperature | -30~+80℃ |
TD4160 TFT LCD Display Module, 4.95-Inch IPS TFT LCD with MIPI
Interface
4.95-Inch Capacitive Touchscreen TFT LCD Display Module Featuring
MIPI Interface
The JT-4.95IPSINCELL is a 4.95-inch TFT-LCD display with a resolution of 540 × 960 pixels and a brightness of 250 cd/m². This module incorporates the TD4160-BOS-HHV30Z-0 controller IC and supports MIPI interfaces. Its overall dimensions are 64.04 mm (W) × 114.98 mm (H) × 2.0 mm (T), with an active area measuring 61.64 mm (W) × 109.58 mm (H). The analog supply voltage (Vdd) for the module ranges from 2.6V to 3.3V, with a typical value of 2.8V.
Featuring an IPS screen, this display module delivers clear visibility from a wide range of viewing angles. The JT-4.95IPSINCELL has an operating temperature range of -20°C to +70°C and a storage temperature range of -30°C to +80°C.
4.95 inch 540*960 TFT Touch Display Module Drawing
Customer Service
1. We provide pre-sales consulting by analyzing project requirements and offering professional, optimized solutions before contract finalization.
2. All inquiries regarding our products or pricing will receive a response within 24 hours.
3. We keep customers informed of production progress and can facilitate factory quality inspections upon request.
4. All LCD displays come with a one-year warranty post-delivery. Defective units will be replaced within the warranty period.
5. Buyers can send technicians to our factory for complimentary training before shipment.
6. We are committed to creating value for our customers. Essential technical or commercial support is available through conference calls, online technical services, or on-site assistance, tailored to meet diverse customer needs.
|
