D28 Welding Table with Accessory Tray for Tools

D28 Welding Table with Accessory Tray for Tools

D28 Welding Table with Accessory Tray for Tools
D28 Welding Table with Accessory Tray for Tools
Categories Welding Fixture Table
Model Number: D28
Leveling Feet: Adjustable ±50 mm, standard supply
Certification: CE
Price: 500-1500 USD
Tabletop Thickness: 25 mm
MOQ: 1 PCS
Delivery Time: 15-25 work days
Per‑leg Load: 900‑1000 kg
Surface Treatment: Gas nitriding
Payment Terms: D/A,L/C,D/P,T/T
Tabletop Material: Q355 steel (mainstream) / HT300 cast iron
Flatness: 0.02mm/m
Supply Ability: 500 units/month
Hole System: D28, Φ28 mm H7, 100×100 mm pitch
Trade Terms: EXW, FOB, CIF, DAP, DDP
Brand Name: WUXI LEMAR
HS Code: 732690/851590
Packaging Details: 4000*2000*200mm
Place of Origin: WUXI , CHINA
Contact Now
Company Info.
Wuxi Lemar Machinery Equipments Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

D28 Welding Table with Accessory Tray for Tools

D28 Welding Table with Accessory Tray for Tools
Product Overview
D28 Welding Table overview showing modular design and accessory tray
Our D28 Welding Table with Accessory Tray for Tools is a heavy‑load modular welding workbench adopting the European D28 hole system. It provides stable, precise clamping for heavy‑weight welding projects, while the dedicated accessory tray offers handy storage for all your clamping tools and welding accessories. Featuring a nitrided Q355 steel top for anti‑slag and wear‑resistant performance, it supports 2D/3D configuration, size customization and optional mobility. Compatible with global D28 clamping accessories, it is ideal for workshops, fabrication shops and robotic welding stations.
Technical Specifications
Hole System StandardD28, hole diameter Φ28 mm H7 tolerance, hole pitch 100×100 mm
Tabletop MaterialQ355 high‑strength steel plate / HT300 gray cast iron; Q355 steel is mainstream option
Tabletop Thickness25 mm (industry standard)
Surface TreatmentGas nitriding, hardness HV550‑900; anti‑weld‑slag, anti‑adhesion, wear‑resistant and rust‑proof
Flatness≤0.1 mm/1000 mm; high‑precision version up to ≤0.05 mm/1000 mm
Common Tabletop Sizes1000×800 / 1200×1000 / 1500×1000 / 2000×1000 / 2400×1200 mm (larger sizes customizable)
Per‑leg Load Capacity900‑1000 kg
Whole‑machine Static Load Capacity5‑10 tons (depends on frame structure)
Accessory TraySteel storage tray, available in drawer‑type / hanging‑type; 1‑2 trays optional
Matching FixturesFully compatible with full‑range D28 standard fixtures (locating blocks, angle brackets, quick clamps, locking pins)
Key Features & Benefits

  • D28 Standard Hole System: High hole accuracy, quick fixture assembly and disassembly, no need for custom tooling, and rapid workpiece switching.
  • Nitrided Surface: Weld slag does not easily adhere to the work surface, is less prone to rust, and experiences minimal wear over long-term use.
  • Tool Tray Included: Fixtures and tools are stored nearby, keeping the work surface tidy, reducing tool loss, and improving workshop efficiency.
  • Heavy-Duty Load Capacity: Suitable for welding large steel structures, vehicle frames, agricultural machinery, and construction machinery.
  • Compatible with Global D28 Fixture Ecosystem: Compatible with European brand D28 fixture accessories.
Certification & Support
  • Certifications: CE (Machinery Directive EN-ISO12100), ISO9001; BV third-party inspection report available.
  • Warranty: Tabletop 1-3 years; accessory tray 1 year; clamps and accessories not covered by the overall machine warranty.
  • After-sales Service: English installation manual provided; remote video debugging; lifetime supply of D28 spare parts.
  • OEM/ODM: Supports custom sizes, laser-marked logos, custom tray styles, and custom surface treatments for welding tables.
FAQ
What trade terms do you support?
We accept EXW, FOB, CIF, DAP, DDP. We can arrange sea freight, air freight or door‑to‑door delivery according to your requirement.
What is the lead time for standard and custom welding tables?
Standard sizes: 12‑18 working days. Custom oversized tables: 20‑30 working days. Lead time will be confirmed before order placement.
Do you offer OEM & ODM services?
Yes. We support custom table dimensions, laser‑engraved customer logo, customized accessory tray style and surface treatment.
What certifications can you provide?
Our welding tables come with CE certification (EN‑ISO12100). We can also supply ISO9001 certificate and BV third‑party inspection report upon request.
Can you provide test report for flatness and hole‑position accuracy?
Yes, the measurement test report is available for extra charge. It is highly recommended for robotic welding projects.
Need a tailored solution for your welding workshop?
Reach out to us today to get your best quote for the D28 Welding Table with Accessory Tray for Tools. Our technical team will reply to you shortly.
