| Categories | Heavy Duty Connector |
|---|---|
| Model Number: | H10A-SF-1L-CV |
| Price: | $5.85 |
| Gender: | Genderless |
| Delivery Time: | 5-7 work days |
| Limiting Temperature: | -40 °C... +125 °C |
| Application: | Robotics,Semiconductor |
| Trademark: | ZJHK |
| Insulation Resistance: | ≥ 1010 Ω |
| Origin: | China |
| Brand Name: | ZJHK |
| MOQ: | 5 |
| Model NO.: | H10A-SF-1L-CV |
| Poles: | 10 |
| Packaging Details: | Standard Packaging |
| Mating Cycles: | ≥ 500 |
| Flammability Acc. to Ui94: | V0 |
| HS Code: | 8536901900 |
| Fastening Type: | Lock Lever |
| Certification: | UL,CQC,CE,UKCA,SGS,EAC,RoHS |
| Payment Terms: | T/T,D/P,L/C |
| Housings: | Metal |
| Transport Package: | Standard Packaging |
| Place of Origin: | China |
| Supply Ability: | 300 pcs within 7 Days |
| Mounting Type: | Surface Mount |
| Company Info. |
| Zhejiang Haoke Electric Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
The H10A heavy-duty connector housing is constructed from high-quality zinc alloy, providing exceptional durability and corrosion resistance. The integrated metal latch ensures secure and easy installation.
Premium rubber seal and precision engineering deliver reliable IP65 protection against dust and water splashes
Ideal for harsh industrial environments and demanding applications
Optional plastic or metal covers protect the insert when not in use
Ensures stable performance and long-term reliability
Featuring a sealed bottom cable entry and reinforced housing construction, this connector provides secure cable connections and maintains reliable IP65 protection. The robust mounting design ensures stable performance even in the most demanding industrial environments.
| Specification | Details |
|---|---|
| Current Rating | 10A |
| Housing Material | Zinc Alloy |
| Protection Rating | IP65 |
| Mounting Type | Surface Mounting |
| Cover Options | Plastic or Metal |
Our products are carefully packaged with multiple protective layers to ensure safety during transportation. High-quality materials and strict standards preserve product integrity, prevent damage, and extend shelf life, guaranteeing that goods arrive in excellent condition for customer satisfaction.
We provide a range of reliable transportation options to meet your specific requirements. Depending on your preferences, you may select from various express delivery services, including FedEx, DHL, UPS, EMS, and more, ensuring timely and secure shipment.
Zhejiang Haoke Electric Co., Ltd. (HAOKE) has secured a front-runner position in the heavy-duty connector arena by integrating the entire value chain-from raw-material smelting to finished-module delivery. Our HA, HE and derivative families offer thousands of mating combinations that serve rail, wind, automation and other demanding segments. Backed by UL,EAC,UKCA,CE,CQC,RoHS,ISO9001 and CQC certifications, Haoke empowers customers to clear worldwide regulatory hurdles with a single part-number solution.
|
