| Categories | Identification Sensors |
|---|---|
| Features: | Long-distance color recognition |
| MOQ: | 1 |
| Response Time: | 200μm |
| Theory: | Photoelectric Sensor |
| Manufacturer Part Number: | BS-500NP |
| Voltage - Supply: | DC12~24V ±10% |
| Place of Origin: | Guangdong, China |
| Certification: | CE |
| Payment Terms: | T/T |
| Price: | $95 |
| Mounting Type: | manual installation |
| Packaging Details: | kraft paper box with carton box; |
| Model Number: | BS-W50N |
| Brand Name: | BOJKE |
| Type: | Color Code Sensor |
| Description: | color mark sensor, Color mark photoelectric sensor |
| Delivery Time: | 5~8 work days |
| Supply Ability: | 150k |
| Usage: | Industrial Automation |
| Output: | RS485 |
| Company Info. |
| Guangdong Boyijingke Sensing Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
BOJKE RS485 Output 200μS Response Time Long-Distance Color Recognition Sensor Mark
| Product Name | Color mark sensor |
| Material | Aluminum alloy |
| Function | Recognize |
| Model | BS-W50N | BS-W50P |
| Output Type | NPN | PNP |
| Type | cable type | |
| Conrol Output | 1 output port, buit in short ciruit protection, and have automatic anti any interference function | |
| Light Source | white LED ,adjustable spot ,minium spot diameter 3.6MM | |
| Response Time | AUTO,C mode and CI mode 200us, at MARK mode 160us | |
| Output Option | LIGHT-ON/DARK-ON | |
| Indicator | Operation indicator light: red infrared, LED display screen | |
| Detection Mode | AUTO,C mod, CI mod and MARK mode sensing distance: 30MM—500MM | |
| Timer | OFF delay/ON delay/one-shot/ON one-shot timer optional,timer range(ms):1ms ~ 9999ms | |
| Conrol Output | NPN open collector/PNP open collector 24V ,Maximum 100mA | |
| Max current consumption 40mA(when connect external, drop voltage:2V | ||
| Power Supply | 12 ~ 24VDC±10%,ripple(P-P): ≤10％ class 2 | |
| Ambient Illuminace | Incandescent lamp: 20,000lux or less Sunlight:30,000lux or less | |
| Consumption Power | Max Voltage:24V, Current within 60MA | Max Voltage: 24V,Current within 60MA |
| Vibration Resistance | 10 ~ 55Hz ,double amplitude 1.5mm ,2 hours in each of the X,Y,Z directions | |
| Ambient Temperature | - 10 ~ +55℃ , no freezing | |
|
