664mm Width RAL 1023 Modular Vehicle Barriers
Mobile Guardrail for Community Construction - Mini Size Vehicle
Stop & Direction Guide
The Mobile Vehicle Barrier (Mini) is specifically designed for work
zone applications. Positioned at the periphery of construction
sites, it effectively stops vehicles from accidentally entering
work areas, ensuring the safety of construction personnel and
drivers.
Constructed from eco-friendly, recyclable aluminum alloy, this
barrier offers non-flammable properties that prevent secondary
combustion from sparks, providing enhanced protection for drivers
and workers.
Lightweight & Easy Operation
The Mobile Vehicle Barrier (Mini) features aluminum profile
construction with auxiliary wheels, making it lightweight and easy
to maneuver. A single operator can install, disassemble, and store
the unit, reducing labor intensity and construction costs.
Impact Test Results from Japan Automotive Research Institute
| Rated Speed | Without Mobile Vehicle Barrier | With One Unit Mobile Vehicle Barrier |
|---|
| 60km/h | 19.5m | 12.9m |
| 40km/h | 9.6m | 8.1m |
Test data demonstrates that when deployed in road maintenance
sections, this barrier significantly reduces vehicle stopping
distances. At 60km/h, the braking distance is shortened by nearly 7
meters, potentially saving the lives of construction workers.
LED Arrow Board Compatibility
Our customized LED arrow board can be mounted on the mobile
guardrail to match its dimensions. Simply place the arrow board at
the handle bend and secure it using the pre-drilled holes. This
provides appropriate viewing height and clear nighttime warnings
with LED illumination.
The arrow board features three lighting modes:
- Continuous lighting
- Tail-to-arrow pattern
- Flashing mode
Product Advantages Comparison
| Comparison Item | RMHs Mini Parking Barrier | Traditional Plastic Cone | Heavy Concrete Barrier |
|---|
| Core Function | Both warns and stops vehicles | Warning only, gets knocked over on impact | Rigid blocking only, can easily damage vehicles |
| Portability | Best: Wheels, foldable, operable by one person | Lightweight but covers small area | Worst: Requires machinery to move |
| Storage & Transport | Extremely space-efficient: Only 20cm thick when folded, fits in car | Fairly space-efficient: Stackable | Extremely space-consuming: Essentially immovable |
| Primary Use Case | Temporary projects requiring real protection (roadwork) | Pure guidance/warning (event queues) | Permanent, fixed isolation (fixed perimeter walls) |
Frequently Asked Questions
Q: What is this mainly used for?
A: It is placed in front of temporary work zones. Its bright color
warns drivers, and if a vehicle accidentally intrudes, it can
buffer and stop the vehicle to protect workers and equipment.
Q: Can one person use it?
A: Yes. It has wheels at the bottom, weighs 20 kg, can be moved
like a cart, and is foldable—all operable by one person.
Q: How do you store it after use?
A: Fold it up. It becomes very thin (about 20 cm thick), can be
stored upright, or easily loaded into an ordinary car's trunk for
transport.
Q: Is it afraid of rain and rust?
A: No. It is made of aluminum alloy with outdoor anti-rust coating,
specifically designed for outdoor use.
Q: What is the most important thing to note when purchasing?
A: The three most critical things:
- Get the report: Ask the manufacturer for the crash test report
- Check sizes: Measure to ensure the deployed size is sufficient and the folded
size fits in your vehicle
- Ask about warranty: Clarify the warranty period and the procedure if it gets damaged
in an impact
