Normalizing Technique 12.7mm PC Steel Strand Cable Unit Weight 7 Wire Low Relaxation

Categories Steel Wire Rod
Model NO.: 1860MPa
Grade: Carbon Steel, Stainless Steel
Reel Weight: 500kg-4tons
Tolerance: 1%
Payment Term: EXW,Fob,CFR,CIF
Delivery Time: Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
MOQ: Usually One Container, May Be Negotiated by Both
Transport Package: Standard Marine Packing
Specification: 1.0mm-120mm
Trademark: XZL
Origin: China
HS Code: 7312100000
Supply Ability: 200000tons/Year
Certification: ISO, CCC, CE
Surface: Spiral
Technique: Normalizing, Quenching
Application: Rope, Packaging, Netting, Manufacturing, Fencing, Construction
Alloy or Not: Non-alloy
Standard: BS, JIS, GB, ASTM, DIN, AISI
Samples: US$ 1/kg 1 kg(Min.Order) | Request Sample
Customization: Available | Customized Request
Place of Origin: China
Price: Negotiable
Packaging Details: Standard Marine Packing
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment,
MOQ: 10ton
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Normalizing Technique 12.7mm PC Steel Strand Cable Unit Weight 7 Wire Low Relaxation

12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel Wire
High Tensile Prestressed Concrete Bonded PT Strands Cables Prestressing Steel Strand Wire Price Cable 12.7mm PC Strand
12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel Wire
Product NamePC Strand
Main executive standardsGB/T5224,ASTMA416,BS5896,JIS3536,ISO6934,EN10138 or as per the technology agreement decided
by both sides after negotiation
Specification1x7 wire,1x2 wire,1x3 wire,1x19 wire
9.53mm,12.7mm,15.2mm,15.7mm,17.8mm,21.8mm
Tolerance0.4-0.15
Product packagingnner diameter:760mm
Outer diameter:1400mm
Width of coil:760mm
Weight of coil:2.5-3.5 tons
Packaging stepsCoils are wrapped by 8 steel strips →wrapped by waterproof cloth →wrapped by 8 steel strips (6+2)→
added with wood pallet
ApplicationPC Strands are mainly used in prestressed concrete structure reinforcement,such as large-span bridges on
railway and highway,overhead crane beam,rock-soil anchoring project,multi-storey industrial buildings,

stadiums,coal mines,etc
Nominal Dia of StrandNumber of Wires in StrandsNominal Dia of Coated WiresWeight of StrandMinimum Breaking Strength of Strand, LBS
Inch (mm)Inch (mm)Lb/1000ft (Kg/1000m)Utilities GradeHigh Strength GradeExtra-High Strength Grade
1/4 (6.35)70.080 (2.03)121 (180)-4,7506,650
9/32 (7.14)70.093 (2.36)164 (244)4,6006,4008,950
5/16 (7.94)70.104 (2.64)205 (305)-8,00011,200
5/16 (7.94)70.109 (2.77)225 (335)6,000--
3/8 (9.52)70.120 (3.05)273 (406)11,50010,80015,400
7/16 (11.11)70.145 (3.68)399 (594)18,00014,50020,800
1/2 (12.70)70.165 (4.19)517 (769)25,00018,80026,900
1/2 (12.70)190.100 (2.54)504 (750)-19,10026,700
9/16 (14.29)70.188 (4.78)671 (999)-24,50035,000
9/16 (14.29)190.113 (2.87)637 (948)-24,10033,700
5/8 (15.88)70.207 (5.26)813 (1210)-29,60042,400
5/8 (15.88)190.125 (3.18)796 (1185)-28,10040,200
3/4 (19.05)190.150 (3.81)1,155 (1719)-40,80058,300
7/8 (22.22)190.177 (4.50)1,581 (2553)-55,80079,700
1 (25.40)190.200 (5.08)2,073 (3085)-73,200104,500
DiameterNumber of wires &diameterApprox.Metallic AreaWeightMinimum Breaking Load-kN
(mm)(mm)(sq.mm(kg/1000mGrade 1100Grade 1300Grade 1500
57x1.7015.913016.519.522.5
67x2.1024.219025.030.034.5
77x2.4031.725033.039.045.0
87x2.8043.134045.053.061.5
97x3.0049.539052.061.070.5
107x3.6071.356074.588.0101.5
127x4.2097.0760101.0120.0138.0
DiameterNumber of wires &diameterApprox.Metallic AreaWeightMinimum Breaking Load -Ibs
(Inches)(Inches)(sq.Inches)(Ilbs/1000ft)Grade 160Grade 180Grade 220
3/16"7x0.0650.0279350040004800
1/4"7x0.0830.04129570064007900
9/32"7x0.0950.051697500850010300
5/16"7x0.1090.0722399001110013600
3/8"7x0.1200.08270120001350016500
7/16"7x0.1440.11389173001950023800
1/2"7x0.1650.15511227002550031200
5/8"7x0.2070.24813358004020049200
12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel WireThe main uses of PC steel strands
PC steel strands are mainly used for the reinforcement of prestressed concrete structures, such as large-span railway and highway bridges, large bridges, silos, buildings, dams, floor slabs, foundations, large concrete containers, atomic reactor buildings, sports venues, airport hangers, prefabricated sections, crane beams, anchors, multi-layer industrial buildings, etc.
12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel WirePC steel stands for "Prestressed Concrete Steel," which refers to high-strength steel wire or strands that are used in the construction of prestressed concrete structures.
In Prestressed concrete, the steel wire or strands are tensioned before the concrete is poured, creating compressive forces within the concrete that offset the tensile stresses that the structure may experience during use.


12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel Wire
We will test the goods before delivery, and also accept the quality inspection of a third party ppointed by the customer.
12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel Wire
Our logistics department is always updated with the special packaging requirements for export consignments.
Our logistics has a good tracking system. You will be kept informed of the shipping status of your shipment until you pick it up.

12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel Wire
Qingdao Xinzhonglian Steel Co., Ltd. is located in Qingdao,China. We are a manufacturer and exporter specialized in the research, production, retail, wholesale, packaging, after-sales of metal materials. We have been engaged in export trade for more than 20 years and have rich experience in this field.
The company adheres to the business philosophy of "service creates value, integrity creates brand", and the corporate spirit of "pioneering and enterprising, tenacious and hardworking, seeking truth and innovation, and win-win cooperation". Based on integrity and with the purpose of providing good professional services, we use our sincere and rigorous management and professional dedication to provide excellent services and high-quality products to our esteemed domestic and
foreign customers in terms of quality, price, and other aspects.
Our major products including Carbon Steel Plate, Carbon Steel Coil, Carbon Steel Pipe, Carbon Steel Bar, Stainless steel plate,Stainless steel coil , Stainless steel pipe, color coated coil, color tile, galvanized sheet, galvanized coil, Galvanized roofing, galvanized zinc,etc. Relying on various products, large inventory, high quality, low price, short delivery time and good after-sales service, and many other competitive advantages, our products are well sold in China and exported to many countries, such as South Korea, Japan, Russia, Germany, Britain, Austria, Czech Republic, Hungary, Netherlands, Slovenia, Bulgaria, Egypt, Saudi Arabia, Iran, Kuwait, UAE, Turkey, Israel, Syria, Lebanon, Jordan, Yemen, Cyprus, Philippines, Vietnam, and Malaysia...
12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel WireQingdao Xinzhonglian Steel Co., Ltd. company always insist on the tenet and business spirit of "survive by quality, develop by reputation", and take quality as the foundation and honesty as the first. At the same time, Xinzhonglian Steel also adheres to the concept of a win-win situation, focusing on customers, and looks forward to becoming your reliable partner.
12.7mm Strand Cables Unit Weight PC Steel Strand Wire 15.2mm 7 Wire Low Relaxation PC Strand Prestressing Steel Wire
