| Categories | UL Electrical Wire |
|---|---|
| Certification: | 3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949 |
| Place of Origin: | Guangdong, China |
| Brand Name: | Linke |
| MOQ: | 1000m |
| Price: | Negotiable |
| Packaging Details: | According to requirement |
| Delivery Time: | 7-15day |
| Payment Terms: | Advance 30% deposit and ship after receiving 70% final payment |
| Supply Ability: | 50000m/day |
| Model NO.: | UL 21481 Cable |
| Insulation Material: | FEP/HDPE/PP/PVC |
| Insulation: | FEP/HDPE/PP/PVC |
| Conductor Type: | Twisted wire |
| conductor material: | copper/Tinned Copper |
| Exterior material: | customize：PVC、PE、LSFOH、silicone rubber |
| insulating materials: | customize:PVC、PE 、XLPE、EPR、SIR |
| colour: | customize |
| package: | By roll |
| Lead Time: | 7-15days |
| Company Info. |
| Linke Cable Technology (DongGuan) CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
UL Style Number: 21481
Rated Voltage: 300V
Rated Temperature: 80℃
Standard: UL758/UL1581
Marking: E364879 AWM 21481 AWG VW-1 80℃ 300V C AWM I A 80℃ 300V FT1 Linke Cable
| Conductor Size (AWG) | Construction (No./mm) | Diameter (mm) | Nominal Thickness (mm) | Diameter (mm) | Core | Shield | Shield Rate (%) | Nominal Thickness (mm) | Diameter (mm) | Max. Conductor Resistance (Ω/KM) Bare Copper | Max. Conductor Resistance (Ω/KM) Tinned Copper |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 26 | 7/0.16 | 0.48 | 0.38 | 1.30±0.10 | 2 | Optional | 0.76 | 4.10±0.15 | 140 | 150 |
Note: Wire specifications can be customized
Black, Brown, Red, Orange, Yellow, Green, Blue, Purple, Gray, White, Yellow/Green, Transparent
Linke Cable Technology Co., Ltd is a leading cable manufacturer in China with over 10 years of experience in R&D, production, and marketing of high-quality cables. We specialize in providing custom cable solutions worldwide.
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
The samples are free for you. New clients are expected to pay for the courier cost.
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Yes, we can print your company name and even customize the quality card to promote your company.
For more information, please feel free to contact us!
|
