| Categories | Skid Steer Loader |
|---|---|
| Brand Name: | KOMAMAX |
| Place of Origin: | Shandong, China |
| Type: | Backhoe Loader, Front Loader, Mini Loader, Skid Steer Loader, Skid Loaders, Log loader, Small Loader/ Middle Loader/ Big Loader |
| Moving Type: | Wheel Loader |
| Warranty: | 1 Year |
| Machine Weight: | 950 kg |
| Hydraulic Cylinder Brand: | Liyuan |
| Hydraulic Pump Brand: | Kawasaki |
| Hydraulic Valve Brand: | Liyuan |
| Engine Brand: | WEICHAI, Popular Science |
| UNIQUE SELLING POINT: | High operating efficiency |
| Power: | 44.7 KW, 37 KW |
| Bucket capacity: | 0.5-0.6m³ |
| Machinery Test Report: | Provided |
| Video outgoing-inspection: | Provided |
| Warranty of core components: | 1.5 years |
| Core Components: | PLC, Pressure vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox |
| Model Number: | JC65 |
| Condition: | New, New |
| Color: | Yellow, Whiete |
| Transport Package: | Container, RO-RO |
| Production Capacity: | 50000unit/Year |
| rated power HP: | 14kw |
| Rated load: | 950kg |
| Maximum load: | 1000kg |
| Applicable Industries: | Manufacturing Plant, Farms, Home Use, Construction works , Energy & Mining |
| Price: | $4,750.00/sets 1-4 sets |
| MOQ: | 1 set |
| Company Info. |
| Shandong Hengjianhang Construction Machinery Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Specifications | |
Rated operating capacity(kg) | 1000 |
Tipping load(kg) | 2000 |
Bucket capacity(m3) | 0.5-0.6 |
Operationg weight(kg) | 3500 |
Max. travel speed(km/h) | 12 |
Hydraulic pump flow(L/min) | 80/132（Hydraulic large flow rate will be charged separately） |
Fuel tank capacity(L) | 90 |
Tires | 12/16.5NHS |
Overall dimensions(mm) | 3580×1880×2150 |
Dimensions | |
Height at maximum extension(mm) | 4070 |
Height to bucket hinge pin(mm) | 3150 |
Width with bucket(mm) | 1880 |
Track width(mm) | 1500 |
Wheelbase(mm) | 1085 |
Ground clearance(mm) | 260 |
Dump angle | 40° |
Dumping height(mm) | 2450 |
Maximum reach(mm) | 710 |
Rollback at ground | 26° |
Angle of departure | 20° |
Engine | |
Maker/Model | Xinchai A498BZG supercharged engine |
Net power | 75hp/2500rpm |
Type | 4Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
Displacement(L) | 3.3 |
Standard | |
Standard bucket | |
Enclosed operator cab | |
Hydraulic joystick controls | |
Auxiliary hydraulic couplers | |
Optional | Prehest starting assist system for extreme cold weather Cab fitted with a heater as standard Air conditioner |
|
