| Categories | Load Cell |
|---|---|
| Brand Name: | OEM,ODM |
| Model Number: | PPM228-1A |
| Certification: | ISO,OMIL |
| Place of Origin: | China |
| MOQ: | 1 |
| Payment Terms: | 30% T/T in advance |
| Supply Ability: | 100sets/month |
| Delivery Time: | within 2 weeks after payment |
| Packaging Details: | The body of truck scale is nude packed and the accessories part are packed in wooden case |
| Description: | Shear beam load cell |
| Sensitivity: | 2 MV/V |
| Creep: | ±0.02%FS/30min |
| Zero balance: | ±1%FS |
| output resistance: | 350±3Ω |
| Company Info. |
| Chongqing Uwhoi Impo&Expo Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
The PPM228-1A Shear Beam Load Cells are available in the capacities
from 0.05t to 1t. Rugged all stainless steel construction and
high performance strain gauges assure superior linearity and
stability.
Capability | 0.05~20 t |
Comprehensive precision | 0.02%FS 0.03%FS |
Sensitivity | 2 mV/V |
Creep | ±0.02%FS/30min |
Zero Output | ±1%FS |
Temperature effect on zero | ±0.02%FS/10ºC |
Temperature effect on output | ±0.02%FS/10ºC |
Operating temperature range | -20ºC~+65ºC |
Input resistance | 380±10Ω |
Output resistance | 350±3Ω |
Insulation resistance | >5000MΩ |
Safe overload | 150%FS |
Bridge voltage | 10V DC |
Material | Alloy or Stainless steel Stainless steel |
Protection class | IP 67 |
Electronic connection | Input+: Red Input-:Black Output+: Green Output-:White |
We have more than 20 years of experience in production, R & D and sales of weighing instruments, and we are still developing and innovating. Located in Chongqing, Southwest China, the company has a good industrial foundation and tradition. The company adheres to the good tradition of Seiko and meticulous work, strictly demands the quality of products, and wins customers with stable and reliable product quality.
|
