| Categories | Gas Detector Sensor |
|---|---|
| Brand Name: | KACISE |
| Model Number: | KAN102 |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1PCS |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 1000 Piece/Pieces per Week negotiable |
| Delivery Time: | 5-8 work days |
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Operating Voltage and Power Consumption: | DC24V ± 6V, ≤ 1.5W (DC24V) |
| Detection Range: | Diffusion type |
| Detection Principle: | Catalytic combustion, Electrochemical, Infrared, PID |
| Communication Distance: | ≤ 1000m (RVSP1.5mm²) |
| Explosion - proof Mark and Protection Level: | Ex db IIC T6 Gb : Ex db IIIC T80°C Db IP66 |
| Electrical Interface: | G3/4" internal thread |
| Company Info. |
| Xi'an Kacise Optronics Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
This detector is compatible with gas sensors such as catalytic, infrared, semiconductor, and electrochemical types. It is designed with a thickened explosion - proof aluminum alloy housing, ensuring stable operation in various industrial explosion - proof environments. As an all - around detector, it can switch among 2/3/4 - wire systems, RS485, and LORA communication by replacing plug - in modules. It is operated with a dedicated infrared remote control. The software is driven by a multi - thread embedded system and programmed with an intelligent human - machine dialogue interface, meeting various functional requirements for gas detection.
| Operating Voltage and Power Consumption | DC24V ± 6V, ≤ 1.5W (DC24V) | Detection Range | Diffusion type |
|---|---|---|---|
| Detection Principle | Catalytic combustion, Electrochemical, Infrared, PID | Communication Distance | ≤ 1000m (RVSP1.5mm²) |
| Electrical Interface | G3/4" internal thread | Explosion - proof Mark and Protection Level | Ex db IIC T6 Gb : Ex db IIIC T80°C Db IP66 |
| Output Capacity | 1 set of passive switch output: 220VAC/24VDC, 2A 1 set of active audible and visual alarm output | Communication and Operation Modes | Infrared remote control, within 8 meters 4 - 20mA three - wire communication, ABUS four - wire system TBUS two - wire system, RS485, LORA communication |
| Alarm Value | Specific parameters of different sensors are shown on the nameplate | Operating Temperature and Humidity | -40°C - +70°C (for combustible gases), -20°C - +40°C, ≤ 93%RH |
| Display Method | 2.1 - inch high - brightness color LED display screen, 4 - digit 8 - segment digital + graphic display | Pressure Range and Response Time | 86KPa - 106KPa, < 30S (T90) |
|
