| Categories | Plastic Welding Machine |
|---|---|
| Place of Origin: | Jiangsu, China |
| Brand Name: | HUITAI |
| Condition: | New |
| Voltage: | 110V/220V/380V/Customize |
| Frequency: | Low Frequency |
| Welding Area: | Depend |
| Dimensions: | (L)500MM*(W)450MM*(H)1000MM |
| Usage: | Plastic Welding |
| Warranty: | 1 Year |
| After-sales Service Provided: | Online support, Video technical support |
| Key Selling Points: | Automatic |
| Applicable Industries: | Manufacturing Plant, Advertising Company |
| Weight (KG): | 50 KG |
| Power (kW): | Ultrasonic |
| Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided |
| Video outgoing-inspection: | Provided |
| Application: | Plastic Welding |
| Cooling Way: | Air Cooling |
| Control: | Semi-Automatic |
| Electric Current: | AC |
| Style: | Vertical |
| Power Ultrasonic: | Ultrasonic |
| Transport Package: | Wooden Case |
| Origin: | China |
| Production Capacity: | 500sets/Year |
| Function: | PE PP PVC Plastic Welder |
| Packaging Details: | Wooden Box |
| Supply Ability: | 100000 Set/Sets per Month |
| Price: | $10,000.00/sets 1-19 sets |
Item | Detailed Information | ||
Equipment Introduction | This equipment has been used in home appliances and medicine and
other fields of hot - melt riveting, temperature control by region. | ||
Japan MISUSI original heating device. Hot plate temperature
control, with self-test, closed-loop control, multi-point
independent temperature control, temperature control accuracy up to
±2 degrees. | |||
The cooling system is air-cooled by blowing air. | |||
Production cycle time 25S-35S. | |||
Equipment Features | Safety: the machine is equipped with protective grating and scald
warning safety baffle. | ||
The work table height is 750MM(Sitting position) | |||
The quipment starting mode: The equipment is started by pushing two
starting buttons together with two hands. | |||
Technical Parameters | Equipment demension(L)500MM*(W)450MM*(H)1000MM. | ||
Maximum allowable die size of equipment(L)300MM*(W)300MM*(H)230MM. | |||
Electric power requiement: 3 phases 380V 50Hz(If there are special
requirements, customer confirmation is required.). | |||
The outlet pressure of the air compressor:
4Kg/cm2-6Kg/cm2(0.4MPA-0.6MPA). | |||
Adaptable to ambient temperature: -5ºC~40ºC | |||
Adaptalbe to humidity : 20%~80% | |||
The noise of the transmission part shall not exceed 70 db. | |||
|
