Product Description:
The Self Lube Wear Plates are designed in a V Block shape, allowing
for easy installation and use. The plates are 100mm in length,
providing ample coverage and protection.
Our Self Lube Wear Plates are made with the highest quality
materials, ensuring long-lasting performance and reliability. These
plates are made with oilless plate technology, which means that
they require no additional lubrication. This makes them ideal for
use in applications where oil or grease would be difficult or
impossible to use.
The Self Lube Wear Plates are also available in a variety of
materials, including bronze guide rail and aluminium bronze plate.
These materials are chosen for their strength, durability, and
resistance to wear and tear.
Overall, our Self Lube Wear Plates are an excellent choice for
anyone in need of high-quality wear products. They are made to the
highest standards, with top-quality materials, and are designed to
provide long-lasting performance and reliability. So if you're
looking for a dependable solution for your wear product needs, look
no further than our Self Lube Wear Plates!
| Material composition and properties table |
| Grade | Bronze Alloy Material |
| Material | CuZn25A15Mn4Fe3 | CuSn5Pb5Zn5 | CuAI10Ni5Fe5 | CuSn12 |
| Density | 8 | 8.9 | 7.8 | 8.9 |
| HB Hardness | >210 | >70 | >150 | >95 |
N/mm²
Tensile Strengt | >750 | >200 | >600 | >260 |
|
| N/mm² Yield Strength | >450 | >90 | >260 | >150 |
%
Elongation | >12 | >15 | >10 | >8 |
|
| Coefficient Linear Expansion | 1.9x10-5/C | 1.8x10-5/C | 1.6×10-5/℃ | 1.8×10-5/℃ |
|
℃
Max.Temp. | -40～+300 | -40~+400 | -40～+400 | 40～+400 |
|
N/mm²
Max.Load | 100 | 60 | 50 | 70 |
|
m/mm
Max.Load(Dry) | 15 | 10 | 20 | 10 |
|
N/mm²*m/mm
Max.PV(Lubrication) | 200 | 60 | 60 | 80 |
|
300N/mm²
Copression Deformation | <0.01mm | <0.05mm | <0.04mm | <0.05mm |
|
| Chemical Requirements |
Copper
Alloy
UNS No. | Composition, % max, except as indicated |
| | | | | Nickel | | | | | | |
| Copper | Tin | Lead | Zinc | Iron | Including | Aluminum | Manganese | Antimony | Sulfur | Phosphorus | Silicon |
| | | | | Cobalt | | | | | | |
| C86300 | 60.0–66.0 | 0.20 | 0.20 | 22.0–28.0 | 2.0–4.0 | 1.0A | 5.0–7.5 | 2.5–5.0 | ... | ... | ... | ... |
| C90500 | 86.0–89.0 | 9.0–11.0 | 0.30 | 1.0–3.0 | 0.20 | 1.0A | 0.005 | ... | 0.20 | 0.05 | 0.05B | 0.005 |
| C91100 | 82.0–85.0 | 15.0–17.0 | 0.25 | 0.25 | 0.25 | 0.50A | 0.005 | ... | 0.20 | 0.05 | 1.0B | 0.005 |
| C91300 | 79.0–82.0 | 18.0–20.0 | 0.25 | 0.25 | 0.25 | 0.50A | 0.005 | ... | 0.20 | 0.05 | 1.0B | 0.005 |
| C93700 | 78.0–82.0 | 9.0–11.0 | 8.0–11.0 | 0.8 | 0.7C | 0.50A | 0.005 | ... | 0.50 | 0.08 | 0.10B | 0.005 |
| A In determining copper minimum, copper may be calculated as copper
plus nickel. |
| B For continuous castings, phosphorus shall be 1.5 % max. |
| C Iron shall be 0.35 % max. when used for steel-backed. |
Features:
- Product Name: Self Lube Wear Plates
- Parts: Self Lube Wear Plate
- Maintenance: Low
- Application: Heavy Duty Machinery
- Load Capacity: High
- Surface Finish: Smooth
- Material: Bronze Guide Slide, Aluminium Bronze Plate, CuAl10Ni5Fe4
Technical Parameters:
| Maintenance | Low |
| Shape | V Block |
| Material | CuZn25AI5Mn4Fe3 (Aluminium Bronze Plate) |
| Wear Resistance | High |
| Length | 100mm |
| Load Capacity | High |
| Bushings | Plug Graphite Bearings (Bronze Guide Slide) |
| Temperature Range | -40°C To 150°C |
| Application | Heavy Duty Machinery |
| Thickness | 6mm |
Applications:
The Self Lube Wear Plates are an ideal solution for heavy duty
machinery that requires high load capacity. These Oil Free Slide
Plates are made from high-quality Bronze Plate with CuAl1Ni
material that ensures durability and long-lasting performance. The
temperature range is between -40°C to 150°C, making it suitable for
various applications.
These Self Lube Wear Plates are perfect for scenarios where the
machinery is subjected to heavy loads and constant friction. The
Plug Graphite Bearings ensure smooth and consistent movement,
reducing wear and tear on the machinery.
The Self Lube Wear Plates can be used in various occasions, such as
in construction and mining machinery, hydraulic cylinders,
agricultural machinery, and other heavy-duty equipment. The product
has been tested and meets INW standards, making it a reliable
choice for any industry.
Investing in the Self Lube Wear Plates from VIIPLUS.COM is a wise
choice for businesses that require high-quality machinery parts.
The product is designed to withstand heavy loads and constant
friction, reducing maintenance costs and downtime. Contact us today
to place your order and take advantage of this reliable and durable
product.
Customization:
Brand Name: VIIPLUS.COM
Model Number: BRONZELUBE
Place of Origin: CHINA
Minimum Order Quantity: 500
Price: can be negotiated
Packaging Details: EXPORT CARTONS
Delivery Time: 15-35 BUSINESS DAYS
Payment Terms: TT
Length: 100mm
Items: Wear Products
Standard: INW
Wear Resistance: High
Parts: Self Lube Wear Plate
Oil Free Slide Plates, CuAl1Ni, CuAl10Ni5Fe4 are available for
customization according to your requirements.
