0.69 Inch OLED Display Module with 96×16 Resolution and I2C Interface

0.69 Inch OLED Display Module with 96×16 Resolution and I2C Interface

0.69 Inch OLED Display Module with 96×16 Resolution and I2C Interface
0.69 Inch OLED Display Module with 96×16 Resolution and I2C Interface
Categories OLED Display Module
Outline Dimension: 24.0mm * 6.9mm * 1.25mm
Type: OLED Display
Brand Name: YZY
Model Number: E069XI-W-C08-04
Certification: CE, ROHS
Place of Origin: Guangdong, China
MOQ: 1000 pieces
Price: $2.6/pieces 100-499 pieces
Payment Terms: T/T
Supply Ability: 10000Pieces
Delivery Time: 14-60 days
Packaging Details: 8*8*4
Resolution: 96 x 16
Active Area: 17.26mm * 3.18mm
Display Size: 0.69 inch
Supplier Type: Manufacturer
Driver IC: SSD1312
Contact Now
Company Info.
Shenzhen YZY Technology Co., Ltd
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

0.69 Inch OLED Display Module with 96×16 Resolution and I2C Interface

0.69 Inch OLED Display Module with 96×16 Resolution and I2C Interface
The 0.69-inch OLED display module is a high-performance passive matrix display featuring monochrome white output and 1/16 drive duty. Its compact, precision-engineered design ensures stable drive control, while the optimized mechanical structure simplifies integration into space-constrained electronic devices.
Key Features
96*16 high-definition resolution with 0.18*0.20mm pixel pitch for sharp text and pattern display
17.26*3.18mm active display area, tailored for small-screen applications
Monochrome white display with reliable passive matrix technology
I2C interface for universal compatibility with mainstream control systems
Ultra-compact module size (24.0*6.9*1.25mm) to save installation space
Wide operating temperature range (-20℃ to +70℃) for diverse environments
RoHS compliant, meeting international environmental safety standards
Technical Specifications
Display Type0.69" OLED
Display ModePassive Matrix
Display ColorMonochrome (White)
Resolution96 * 16
Driver ICSSD1312
Drive Duty1/16 Duty
Module Size24.0(W) * 6.9(H) * 1.25(T) mm
Active Area17.26(W) * 3.18(H) mm
Pixel Pitch0.18(W) * 0.20(H) mm
InterfaceI2C
Operating Temperature-20℃ to +70℃
Storage Temperature-30℃ to +80℃
RoHS ComplianceYES
Applications
Ideal for space-constrained devices including portable instruments, smart sensors, industrial controllers, and Arduino-based projects. The compact form factor provides flexibility for product structure design, while stable performance ensures reliable operation in various scenarios.
Reliability & Performance
This module adopts a robust passive matrix design and undergoes strict quality control, ensuring long-term stable operation without performance degradation. Its wide temperature adaptability and precise mechanical dimensions make it a reliable choice for small-screen display needs, with low integration failure risk.
Module Dimensions
Various Application Scenarios


Manufacturing Technique

Packaging & Shipping
