Developed exclusively for the outdoor DOOH (Digital Out-of-Home) market, the NOX Series stands as a flagship ultra-high-definition
(UHD) LED display solution from LP DISPLAY. Engineered to merge
cinematic visual clarity with rugged outdoor resilience, it
transforms exposed public spaces into high-engagement digital
touchpoints—delivering eye-catching content that cuts through
sunlight, weather, and urban noise for audiences in transit hubs,
city plazas, retail exteriors, and Culture and Tourism landmarks.
At the heart of the NOX Series is its native 4K UHD resolution (3840×2160)—a game-changer for outdoor DOOH, where content must capture
attention quickly from near and far. Paired with ultra-fine pixel
pitches (ranging from 1.92mm to 3.91mm), this UHD foundation
ensures:
- Close-Range Clarity: 1.92–2.5mm pixel pitches render fine text (e.g., promotional
prices, event details) and high-res product imagery legible for
pedestrians within 3–5 meters (ideal for retail storefronts or mall
entrances).
- Mid-to-Far Visibility: 3.0–3.91mm pitches maintain sharpness for audiences 10–20 meters
away (perfect for highway billboards, transit station concourses,
or large plaza screens).
- Wide Color Gamut: Calibrated to 95% DCI-P3, the series reproduces vivid, true-to-life hues—from the saturated
reds of a brand logo to the subtle gradients of scenic video
content—ensuring visuals stand out against busy outdoor backdrops
(e.g., urban buildings, greenery).
- Deep Contrast & Flicker-Free Motion: A 1,000,000:1 contrast ratio delivers inky blacks and bright highlights, while a 3840Hz high refresh rate eliminates motion blur and flicker. This makes dynamic content
(e.g., car ads, sports highlights, real-time news) smooth and
engaging—even for fast-moving drivers or pedestrians.
Outdoor DOOH demands uncompromising resilience against the
elements, and the NOX Series delivers with multi-layered protection technology:
- Seamless Sealing: Every panel joint uses military-grade silicone gaskets, and cable
entries feature waterproof connectors—shielding internal components
(drivers, receiver cards) from heavy rain (up to 100mm/h), dust
storms, and morning dew.
- Weatherproof Ventilation: Rear cabinets integrate dust-proof/waterproof membrane vents that
release heat without letting in moisture, critical for humid
coastal regions or rainy climates.
- Rust-Proof Materials: The cabinet adopts anti-corrosion die-cast aluminum (treated with electrophoretic coating) and 304 stainless steel
hardware, resisting salt spray (coastal areas) and industrial
pollutants (urban centers) for 5+ years.
- UV-Stabilized Panel: The surface uses imported anti-UV tempered glass, preventing
yellowing, embrittlement, or brightness decay after prolonged
exposure to direct sunlight—maintaining UHD clarity for a decade.
- Wind & Impact Resistance: The one-piece die-cast aluminum cabinet withstands wind loads up
to 150km/h (typhoon level 12) for rooftop or high-altitude installations. Its
4mm-thick anti-impact tempered glass (Mohs hardness ≥7) protects
LED chips from hail, wind-blown debris, or accidental collisions.
- Wide Temperature Adaptability: An intelligent thermal management system (low-noise fans +
heat-dissipating fins) maintains internal temperatures between -30°C and 60°C, ensuring normal operation in frigid winters (e.g., northern
China) or scorching deserts (e.g., the Middle East).
The NOX Series is engineered to simplify deployment, reduce
maintenance, and lower operational costs for DOOH operators:
- Standardized Cabinets: Available in 500×500mm and 1000×500mm panels (weight:
15–22kg/panel), supporting seamless splicing into custom sizes—from
compact 2×1m bus stop screens to sprawling 10×5m city billboards. A
tool-less quick-lock system cuts installation time by 60% (a 3×2m
display assembles in under 1 hour).
- Adaptive Brightness: A built-in light sensor automatically adjusts brightness between 1500–2500 nits—cranking up at noon to combat direct sunlight, dimming at dusk to
save energy, and switching to "night mode" (500 nits) to avoid
light pollution.
- Low-Power Operation: Equipped with high-efficiency LED drivers, the series reduces
power consumption by 25% compared to conventional outdoor displays—critical for 24/7
operations that face rising electricity costs.
- CMS Compatibility: Integrates with mainstream DOOH content management systems (e.g.,
BroadSign, Scala) via 5G/Wi-Fi, enabling remote content updates,
schedule management, and real-time status monitoring (temperature,
power, pixel health).
- Front-Access Maintenance: Modules can be replaced from the front of the display,
eliminating the need for rear access (ideal for screens mounted
against buildings or narrow billboard structures). Optional dual
power supplies and signal cards provide failover protection,
avoiding costly ad downtime.
The NOX Series excels in high-impact outdoor scenarios where UHD
clarity and durability are non-negotiable:
For outdoor DOOH operators and brands, the NOX Series solves the
longstanding tradeoff between "visual quality" and "outdoor
durability." It delivers UHD clarity that rivals indoor displays,
paired with the ruggedness to survive extreme weather—all while
optimizing for the speed, efficiency, and cost savings critical to
DOOH success. More than a display, it’s a reliable, high-return
tool for turning outdoor spaces into attention-grabbing digital
assets.
