Wind Off-Grid Controller AHCC 40Aac/80Aac MPPT for 5KW-30KW Systems

Categories Off Grid Controller
Rated Input Current: 40Aac/80Aac
Rated Wind Power: 5KW/10kw/20kw/30kw
Maximum withstand voltage: 290Vac-530Vac/600Vac For 5 Seconds
MPPT voltage range: 90~520V Customized/220~530Vac
Rated voltage: 48Vac-380Vac
Application: Solar System Or Wind Turbine Or Generator System
Communication interface: Standard: RS485/TCP
Battery Type: Lead-acid Batteries, Lithium Batteries, DC Bus Bars, Etc.
Brand Name: Greef
Model Number: AHCC
Place Of Origin: CHINA
Certification: CE
MOQ: 1Set
Price: Negotiable
Packaging Details: Foam+plywooden Case
Delivery Time: 25 Working Days
Payment Terms: T/T,Western Union,,L/C
Supply Ability: Supply Ability
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Wind Off-Grid Controller AHCC 40Aac/80Aac MPPT for 5KW-30KW Systems

Control Your Wind System with Wind Controller AHCC Rated Input Current 40Aac/80Aac
Product Description
The GREEF wind off-grid controller is a critical component in wind generator systems, converting three-phase AC current from wind turbines into DC current to charge battery banks. Featuring dedicated MPPT technology, this controller significantly enhances electricity production while incorporating advanced features like modular design, electrical isolation, PWM unloading, and host computer control.
With its large touchscreen and IoT functionality, the GREEF controller enables efficient, safe, and intelligent power generation while supporting comprehensive operation and maintenance management.
Key Features
  • Power Tracking: Wind energy MPPT with 98% engagement with actual wind energy output curve for enhanced power generation
  • Safety Protection: Over-voltage, over-current, anti-reverse connection, and short circuit protection
  • IoT Functionality: Wired network support with APP remote view and control, plus remote data export capability
  • Touch Screen Interface: Displays voltage, current, power, power generation, and operation status with alarm query and historical data review
  • Custom Power Absorption Circuit: Modularized, hot-swappable design with input/output electrical isolation and high efficiency at low wind speeds
  • PWM Unloading: Fan self-powered mode with fast response, speed/torque limiting, and soft unloading adjustment
Technical Specifications
ModelAHCC-5KWAHCC-10KWAHCC-20KWAHCC-30KW
Rated power5KW10KW20KW30KW
Product TypeMPPT, high frequency isolated new energy converter
DC Output Side
Type of energy storageLead-acid batteries, lithium batteries, DC bus bars, etc.
Rated output current100A200A80A150A
Output Voltage Range42-240Vdc (adjustable)200-1000Vdc (adjustable)
Wind Turbine Input Side
Rated voltage48Vac-380Vac380 Vac
Maximum withstand voltage290Vac-530Vac for 5 seconds600Vac for 5 seconds
MPPT voltage range90~520V customized220~530Vac
Maximum power10kW20kW40kW60KW
Rated Input Current40Aac80Aac40Aac80Aac
Working Environment Conditions
Ambient temperature-25℃~50℃
Storage temperature-40℃~75℃
Relative humidity0 to 95%
Product Images
GREEF Wind Controller AHCC front view GREEF Wind Controller AHCC side view GREEF Wind Controller AHCC touchscreen interface GREEF Wind Controller AHCC internal components
System Solution
We can tailor a system to your specific needs. Please contact us to learn more about our products.
Wind energy system installation example
Product Packaging
GREEF Wind Controller AHCC packaging
