HT300 3D Welding Table Quick Release Fixture For Batch Production Small Hardware

D16 Quick release Fixture Table for Batch Production of Small Hardware is a flexible fixture platform with D16 hole system, quick disassembly and assembly, modularity, and high repeatability positioning. It is designed for batch welding/assembly/testing of small hardware, stamping parts, sheet metal parts, fasteners, and small metal components. The core is D16/50mm hole system+quick locking pin+micro fixture+second level clamping, focusing on batch consistency, quick changeover, zero tools, and high cost-effectiveness.

Workshop adaptability

Multi station linkage, adapted to assembly line production

• It can seamlessly integrate with small stamping machines, spot welding machines, and polishing machines as an intermediate positioning/assembly platform, achieving a one-stop flow of "stamping welding assembly testing".
• Support left/right/front/back splicing to form a linear fixture line, suitable for batch continuous processing of long strip hardware (such as slides, connecting rods).

Ergonomic design to reduce operator fatigue

• The height of the workbench can be fine tuned between 750-850mm, suitable for operators of different heights; The edges of the countertop should be rounded and polished to avoid bumps and scratches.
• The fixture operation is highly suitable for the optimal force range of human hands, with quick disassembly and assembly in 10 seconds, reducing repeated bending and lifting movements, and reducing long-term work fatigue.

Product Compliance

Low energy consumption and noise control

• Pure mechanical quick release structure, no need for electric drive, zero energy consumption; The noise level during fixture locking/loosening is ≤ 50dB, far below the workshop equipment noise standard, creating a quiet production environment.
• No hydraulic/pneumatic pipelines, avoiding oil leakage and pollution of workpieces and the ground, and keeping the workshop clean.

Safety compliance certification

• The D16 Quick release Fixture Table for Batch Production of Small Hardware has passed ISO 9001 quality management system certification, and the load-bearing capacity and fixture strength of the countertop comply with EN 1090 steel structure safety standards.
• The fast locking pin anti loosening design has passed fatigue testing (100000 times opening and closing without failure), ensuring no safety hazards in mass production.

Extension of usage scenarios

D16 Quick-release Fixture Table for Batch Production of Small Hardware Not only suitable for welding small hardware, but can also be extended to multiple production processes to improve equipment utilization:

• Precision assembly: As the assembly reference platform for small hardware components such as hinges and locks, the hole system is used to accurately locate each component, ensuring uniform assembly clearance and high consistency.
• Size detection: Paired with a digital caliper and dial gauge, it serves as a testing platform for small hardware components. By quickly calibrating the workpiece reference through positioning blocks, it improves detection efficiency and accuracy.
• Polishing/Grinding Assistance: After clamping small hardware components, it can be used as a fixed platform for polishing and grinding, avoiding dimensional deviations and safety hazards caused by manual holding of workpieces.
