SAER Large Format Impresora 3200mm 4pcs & 8pcs i3200A1 Print Head Digital Fabric Plotter

Categories Epson Head Printer
Brand Name: SAER
Model Number: CSR3200
Certification: CE Certification
Place of Origin: Shanghai, China
MOQ: 1 set
Price: Negotiation
Payment Terms: T/T,Western Union
Supply Ability: 50 sets per month
Delivery Time: 15 work days
Packaging Details: Non-fumigation wooden box
Sofware: ONYX
Machine working power: 7kw
Automatic Grade: Automatic
Suitable Fabric Type: Polyester & Cotton
Media Processing: Roll To Roll + Auto Feeding + Auto Roll Up
Ink Type: Sublimation ink, Pigment ink
Power supply: AC380, 50/60HZ
Color & Page: Multicolor
Usage: Indoor & Outdoor Advertising Field
Compatible OS: Windows 7& Windows 10
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

SAER Large Format Impresora 3200mm 4pcs & 8pcs i3200A1 Print Head Digital Fabric Plotter

SAER Large Format Impresora 3200mm 4pcs & 8pcs i3200A1 Print Head Digital Fabric Plotter
Product Overview

Advanced digital fabric printing system designed for textile factories, featuring environmentally friendly operation and high-performance i3200 print heads.

Technical Specifications
Model TypeCSR3200
Print Head4 pieces i3200A1
Ink TypesSublimation ink, pigment ink
Number of Nozzles(400 nozzles × 8 lines) × 4 heads
Color ConfigurationDual CMYK
Print Head Height1.5mm/6mm (adjustable)
Ink Supply ModeContinuous ink supply
Max Materials Width3300mm
Max Printing Width3200mm
Roll Outer Diameter3 inch
Maximum Roll Weight100kg
InterfaceUSB 2.0
RAM128M
Printer PowerAC380V, 50/60HZ
Power ConsumptionHeater: 3KW, Printer: 4KW
Operating Temperature30-32℃
Operating Humidity40-60% (Non-condensing)

Printing Speed & Resolution
Resolution (dpi)Speed
720×1200 dpi (4 pass)78 m²/h
720×2400 dpi (8 pass)52 m²/h
360×1200 dpi (2 pass)136 m²/h
Key Features
Guide Rail: HIWIN mute guide rail with Germany IGUS silent drag chain for quiet printing environment.
Print Head: Four i3200A1 print heads for faster speed and longer lifespan. Feather printing function, easy correction and counterpoint. Intelligent cleaning system.
Axis System: X and Y axis equipped with AC servo motors for precision movement.
System Advantages
  • Smooth fabric take-up and feeding operation
  • Inflatable take-up and feeding rollers
  • Unique filtering lampblack system for clean picture quality
  • Feeding motor with positive and negative transfer function
  • Constant tension transmission system
Application Industries
  • Clothing industry: sample printing and character pattern color printing
  • Personality printing: shops, cell phone decoration, gift shops
  • Studio: digital image production
  • Advertising industry: indoor and outdoor advertising
  • Product proofing: traditional printing sample production
Professional Services
SAER Digital Fabric Printing System in operation Technical specifications diagram of printing system
Logistics Service
Packaged printing system ready for shipment
Frequently Asked Questions
How can I place an order? Contact us with your order details, we will prepare the Proforma Invoice.
How can I pay? We accept T/T and Western Union payments.
Do you supply ink and materials? Yes, we recommend using original ink for optimal printer maintenance and can supply related materials.
Can you help with business setup? Yes, we can provide project ideas based on your product requirements and business goals.
What is the after-sale service? 12-month machine guarantee (print heads excluded). Online technical support even after guarantee period.
