Efficient Stable 3200mm Large Format Digital Textile Printing System Digital Plotter Direct to Fabric

Categories Epson Head Printer
Brand Name: SAER
Model Number: CSR3200
Certification: CE Certification
Place of Origin: Shanghai, China
MOQ: 1 set
Price: Negotiation
Payment Terms: T/T,Western Union
Supply Ability: 50 sets per month
Delivery Time: 15 work days
Packaging Details: Non-fumigation wooden box
Sofware: ONYX
Machine working power: 7kw
Automatic Grade: Automatic
Suitable Fabric Type: Polyester & Cotton
Media Processing: Roll To Roll + Auto Feeding + Auto Roll Up
Ink Type: Sublimation ink, Pigment ink
Power supply: AC380, 50/60HZ
Color & Page: Multicolor
Usage: Indoor & Outdoor Advertising Field
Compatible OS: Windows 7& Windows 10
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Efficient Stable 3200mm Large Format Digital Textile Printing System Digital Plotter Direct to Fabric

Product name: Efficient Stable 3200mm Large Format Digital Textile Printing System Digital Plotter Direct to Fabric

Machine Main Features :

X axis and Yaxis:
X axis and Y axis are using AC servo motors.

Guid Rail: Using HIWIN mute guide rail. Germany IGUS silent drag chain make your printing environment more quit .

Print head: Four pcs i3200A1 Print head, faster speed, longer head life time. Feather printing function available, print heads correction and counterpoint are more easy. Intelligent print head cleaning service, supply safe and convenient print head cleaning and protection function.

Printer working speed:


Printing resolution and speed

Resolution(dpi) speed
720*1200dpi(4 pass) 78m2/h
720*2400dpi(8 pass) 52m2/h
360*1200dpi(2 pass) 136m2/h

Machine Specifications:

Product Parameter
Model typeCSR3200
Print head4 pieces i3200A1
InkSublimation ink, pigment ink
Number of nozzles(400 nozzles*8lines)*4head
ColorDual CMYK
Print head high1.5mm/6mm (adjustable)
Ink supply modeContinuous ink supply
Max materials width3300mm
Max printing width3200mm
Roll outer diameter3 inch
Maximum weight for roll material100kg
InterfaceUSB2.0
RAM128M
Printer PowerAC380V ,50/60HZ
PowerHeater 3KW
Printer 4KW
Temperature30-32℃
Humidity40-60%(Non-condensing)

Advantages:

  1. Unique filtering lampblack system, make the picture very clean.
  2. Taking up and feeding fabric are smoothly
  3. Taking up and feeding roller are inflatable roller.
  4. Equipped with the feeding motor Positive and Negative transfer function, taking and feeding constant tension transmission system.

FAQ:


1) I want to open a new business, can you give me some ideas?
A: Yes, we can, please tell me what products you want to make, and your request, we can offer you some projects.

2) If I buy the machine, can you supply the ink, material, etc also?
A: Yes sure, please use the Original ink, it's better for the printer maintance, we can supply the relate material also.

3) How can I place order?
A: Contact us about your order details,we will prepare the PI .

4) How can I pay you?
A: Uaually we accept T/T, Western Union

5) How about the after-sale service?
A: Machine guarantee 12 month, printheads are no guarantee. We supply the on line technology even machine out of guarantee.


Professinal Service:

Automatic Digital 6 Feet Roll to Roll and Flatbed UV Hybrid Inkjet Printer 2

Logistics Service:
Automatic Digital 6 Feet Roll to Roll and Flatbed UV Hybrid Inkjet Printer 3

Application industry:

  1. Clothing industry: sample print or character pattern of color printing.
  2. Personality print: such as shops, cell phone decoration shop, personality gift shop.
  3. Studio: digital image production.
  4. Advertising industry: indoor and outdoor advertising.
  5. Products proofing: all kinds of traditional printing sample production.


Pack & Shipping:
