Teledyne CLASS E-2 | C57283-E2 Long-Life Oxygen Sensor for N₂ Purity

Teledyne CLASS E-2 | C57283-E2 Long-Life Oxygen Sensor for N₂ Purity

Teledyne CLASS E-2 (P/N C57283-E2) micro-fuel cell oxygen sensor. Measures trace O₂ in nitrogen liquefaction, 0–100 ppm range, 24-month service life.

Product Overview

The Teledyne CLASS E-2​ (Part Number C57283-E2) is a long-life electrochemical micro-fuel cell​ designed for trace oxygen monitoring​ in nitrogen liquefaction and air separation processes. It is specifically engineered for use in Teledyne Model 3290 analyzers deployed on unattended nitrogen skids, offering extended service life and stability in demanding industrial gas applications.

Technical Specifications (Electrical & Performance)

Parameter

Specification

Manufacturer / Series

Teledyne Analytical Instruments / CLASS E

Model / Part Number

CLASS E-2 (C57283-E2)

Sensor Type

Electrochemical Micro-Fuel Cell (Sealed)

Primary Application

Trace O₂ in Nitrogen (N₂ liquefaction processes)

Typical Measurement Range

0 – 100 ppm O₂ (or 0–1000 ppm)

Output Signal

Current (µA), proportional to O₂ partial pressure

Response Time (T90)

< 10 seconds (typical for step change)

Warranty / Service Life

24 months (typical in specified application)

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Housing Dimensions

Ø 1.25 inch (31.75 mm) x 0.75 inch (19 mm) thick

Sensing Area

Ø 0.7 inch (Large area to minimize condensation error)

Electrical Connection

2 concentric foil contacts (rear-mounted)

Operating Temperature

0 °C to +45 °C (recommended range)

Sample Flow

Diffusion-controlled (unaffected by flow rate variation)

Orientation

Insensitive to shock, vibration, or mounting position

Compatible Analyzers

Teledyne 3290 Series (Unattended Nitrogen Skids)

Key Features

  • Extended Service Life:​ Optimized for long-term stability in continuous nitrogen monitoring applications.

  • Maintenance-Free Operation:​ Sealed, disposable design with no electrolyte refilling required.

  • True Zero Reading:​ Generates zero current in the absence of oxygen, eliminating the need for zero gas.

  • High Specificity:​ Minimal cross-sensitivity to other gases, ensuring accurate O₂ measurement.

Applications

  • Nitrogen purity monitoring in liquefaction plants

  • Inert gas blanketing and purging systems

  • Air separation unit (ASU) gas analyzers

  • Unattended industrial gas safety monitoring
