Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission

Categories	Video Data Link
Brand Name:	Hincn
Model Number:	HCL536-300mW
Place of Origin:	China
MOQ:	1 set (2 pcs)
Price:	US$539~US$699
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	1,689sets/month
Delivery Time:	7~14 working days
Packaging Details:	carton package
Modulation:	TDD OFDM
Frequency:	806~826MHz,1428~1468MHz,1420~1530MHz
Bandwidths:	1.4/3/5/10/20MHz
Throughput:	Maximum 30Mbps@20MHz
FHSS:	Support
Networking mode:	Point-to-Point, Point-to-Multipoint, Relay
Encryption:	AES128
OEM/ODM:	Support

Contact Now

Add to Cart

Company Info.

Hincn Limited

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Wireless HD Video Data Link for UAVs & Drones – Real-Time HD Transmission

Wireless HD Video Data Link for UAVs & Drones

The HCL536 delivers real-time HD video from your drones or UAVs with ultra-low latency. Perfect for aerial photography, FPV applications, and real-time monitoring.

Key Features

Long-range transmission capability
Secure and stable connection
Easy integration with drones
Real-time HD video transmission

Technical Specifications

Radio

Frequency	806~826MHz, 1428~1468MHz, 1420~1530MHz (customizable)
Bandwidth	1.4/3/5/10/20MHz
RF Power	300mW
Modulation	OFDM
Constellation	BPSK; QPSK; 16QAM
Duplex	TDD
Throughput	Up to 30M bps
Encryption	AES128

Power

Air Unit	300mW×2
Ground Unit	300mW×2

Size and Weight

Air Unit	103.461.422mm / 142g
Ground Unit	103.461.422mm / 142g

Connectivity

Antenna	SMA×2
Video Interface	Ethernet×2
Other Interface	3 channels, 3RS232, 3TTL or 2RS232/TTL + 1Sbus

Environment

Working Temperature	-40°C~60°C

Device Appearance

HCL536 Wireless HD Video Data Link device showing compact design and connectivity ports

Application

Frequently Asked Questions

Q1. This video data link supports IP camera. What if I want HDMI or SDI video input?

The default video input is IP RJ45 Ethernet port. For cameras with HDMI, SDI, AHD or AV output, we recommend using our mini encoder device to encode the video/audio signal into digital data for transmission. At the receiver end, you can connect directly to your computer or NVR. For HDMI monitor output, our decoder device can convert the digital data back into HDMI video and audio signals.

Q2. For the 800MHz and 1.4G band, which one would be better?

If your local area has DVB-T or DVB-T2 digital television signal in the 170-860Mhz range, the 1.4G band would be better. Additionally, since GPS antennas on drones point upward and transmitter antennas point downward, the 1.4G frequency has negligible effect on GPS signals.

About Us

Hincn Limited is a Hong Kong company specializing in HD video wireless communication solutions, founded in 2018. Our research and production center is located in Shenzhen and was established in 2015. We have a total of 13 employees, including 3 programmers and 2 engineers. Our company has a long-term cooperative relationship with ADI, Xilinx, Altera and Morningcore. We are the third-party design partner for both ADI and Morningcore.

Hincn Limited company information and credentials
