LIGHTLINK OAK 2.6 Indoor scnree

LIGHTLINK OAK 2.6 Indoor Screen
Product Features
  • Adopts high-quality Nationstar LED lamps; PCB utilizes second-generation anti-collision pad technology, effectively reducing lamp failure and falling off
  • Adopts IC Pulse Width Modulation (PWM) technology, which effectively improves the refresh rate and gray scale level of the LED display
  • Adopts Power Factor Correction (PFC) technology, enhancing the power conversion and utilization rate of the LED display (≥92%)
  • Equipped with signal backup function and RJ45 signal backup network port to ensure stable and lossless picture display
  • Modular design, supports full front / full rear maintenance for modules, and the control box can be disassembled independently
  • Ultra-light and ultra-thin design, with a single cabinet thickness of 63.5 mm and a weight of only 6.8 kg
Product Specifications
ItemSpecification
Pixel Pitch (mm)2.6
LED TypeSMD 1515
Scanning Mode1/24 Scan
Module Resolution (pixels)96 * 96
Module Size (mm)250 * 250
Pixel Density (pixels/m²)147,456
Brightness (cd/㎡)800-1000
Viewing Angle (Horizontal / Vertical)H: 140° V: 140°
Cabinet Size (mm)500 * 500 * 63.5
Cabinet MaterialDie-cast Aluminum
Cabinet Weight (kg)≈ 6.8
Refresh Rate (Hz)≥ 3840
Input Voltage (V)AC 110V, 220V, 110-240V
Input Power Frequency (Hz)50 / 60
Maximum Input Power (W/m²)Approx. 600
Product Images
LIGHTLINK OAK 2.6 Indoor LED Display front view LIGHTLINK OAK 2.6 Indoor LED Display side view LIGHTLINK OAK 2.6 Indoor LED Display close-up detail LIGHTLINK OAK 2.6 Indoor LED Display installation view
