| Categories | Welding Fixture Table |
|---|---|
| Brand Name: | WUXI LEMAR |
| Model Number: | D28 |
| Certification: | CE |
| Place of Origin: | WUXI |
| MOQ: | 1 PCS |
| Price: | 500-1000 USD |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability: | 500 units/month |
| Delivery Time: | 15-20 work days |
| Packaging Details: | 3000*2000*200mm |
| Overall Size: | 2000mm × 1500mm |
| Hole Diameter: | Φ28mm |
| Grid Spacing: | 100mm |
| Tabletop Thickness: | 25mm |
| Material: | Q355 Steel / HT300 Cast Iron |
| Flatness Tolerance: | ≤0.3mm / 1000mm |
| Surface Treatment: | Black Oxide / Optional Gas Nitriding |
| Leg Type: | Adjustable Leveling Legs（Standard） |
| Optional Accessory: | Moving Caster Base |
| Company Info. |
| Wuxi Lemar Machinery Equipments Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Our D28 2D Modular Welding Table 2000mm x 1500mm is a heavy-duty, high-precision modular welding fixture platform. Adopting standard D28 100mm grid hole system, it supports full modular clamping, positioning and assembly. Ideal for custom metal fabrication, frame welding, chassis assembly and robotic welding workstation layout. It perfectly fits small to medium workpieces and batch production demands.
| Table size: | 2000mm × 1500mm, with a thickness of approximately 25mm |
|---|---|
| Reference hole: | 28mm in diameter, with a grid spacing of 100 ± 0.05mm, evenly distributed throughout the entire tabletop |
| Flatness: | 0.3mm/1000mm (high-precision level) |
| Verticality: | 0.1mm/200mm (side to table) |
| Surface hardness: | about 20HRC (wear-resistant, slag resistant) |
| Material: | HT300 cast iron (stress relieved, non deformed) or Q355 steel (heavy-duty) |
| Working face: | 5 faces (tabletop+4 sides) can be positioned and clamped |
| Supporting feet: | Standard fixed feet, adjustable feet (700-900mm), and optional wheeled mobile feet |
This D28 welding table is fully CE certified according to EU Machinery Directive and EN 1090 standard.
Automotive frame, engineering machinery, steel structure, cabinet chassis, agricultural equipment, logistics racking, rail transit parts, robotic welding cell and custom metal fabrication workshop.
Can I add moving casters?
Yes. We offer optional brake caster base, convenient to move the
table to different workstations and lock steadily.
Can I splice several tables together?
Yes. Multiple 2000×1500mm tables can be freely spliced to make a
larger working area for extra-long or super-large workpieces.
What is the packing and shipping way?
Export standard fumigated wooden box packaging. Perfect size for FCL or LCL sea shipping, suitable for
EU and global container loading.
Can you customize size, color or structure?
Yes. Custom size, table thickness, base height, industrial painting
color and special structure design are all acceptable.
|
