| Categories | Automatic Die Cutting Machine |
|---|---|
| Model Number: | CC450S |
| Die Cutting Accuracy: | ±0.15mm |
| MOQ: | 1 |
| Total Power: | 13KW |
| Certification: | CE |
| Max. Die Cutting Area: | 500×300mm² |
| Brand Name: | DaYuan |
| Max. Punching Speed: | 450 strokes per minute |
| Machine Dimension: | 3000×1500×1750mm (L×W×H) |
| Place of Origin: | china |
| Power Supply: | 380V/50Hz 3PH+N+PE |
| Company Info. |
| Dayuan Industrial Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
The CC450-S Automatic Cup Lid Die Cutting Machine from Dayuan Machinery delivers high-speed precision manufacturing with 450 strokes per minute multi-axis servo high precision punching capability. This advanced equipment creates hermetic, puncture-resistant seals essential for dairy product freshness through hydraulic or rotary stamping of continuous rolls of aluminum foil or plastic.
The CC450-S is engineered for high-precision die cutting of yogurt cup lids, ice cream easy-tear sealing gaskets, milkshake sealing films, coffee cup easy-peel films, sauce cup lids, and tea can aluminum foil films. Equipped with multi-axis full servo control system and five-linkage die cutting structure, it achieves maximum punching speed of 450 strokes per minute with die cutting accuracy of ±0.15mm, featuring optional embossing device. This machine serves as core production equipment for food packaging enterprises, dairy factories, and fast food packaging plants.
Advanced five-linkage die cutting structure with optimized punching path and motion trajectory delivers maximum punching speed of 450 strokes per minute. This provides single-line production capacity far exceeding conventional models, easily handling large-volume cup lid and sealing film orders with stable punching action that extends mold service life.
Multi-axis full servo motor system provides servo drive for main motor, embossing, feeding, storage, and edge material traction. This ensures stable operation without jitter, achieving die cutting positioning accuracy of ±0.15mm, producing cup lids with burr-free and indentation-free edges with high consistency.
Features include mold with vacuum adsorption anti-drop function, automatic counting system, and edge material automatic winding mechanism, reducing manual intervention throughout the process. Easy operation enables quick startup after simple training.
Quick-change mold structure design enables complete mold replacement in approximately 1 hour, supporting fast switching of multi-specification products and adapting perfectly to small-batch and multi-batch customized production needs.
Compatible with various common food packaging materials:
Designed and manufactured in accordance with EU CE standards with CE certification obtained. Key components from internationally renowned brands ensure full compliance with domestic and international food contact packaging production requirements.
| Item | Technical Parameters |
|---|---|
| Model | CC450-S Automatic Cup Lid Die Cutting Machine |
| Power Supply | 380V/50Hz 3PH+N+PE |
| Total Power | 13KW |
| Max. Punching Speed | 450 strokes per minute |
| Max. Roll Diameter | 800mm |
| Max. Roll Width | 520mm |
| Die Cutting Accuracy | ±0.15mm |
| Max. Die Cutting Area | 500×300mm² |
| Mold Replacement Time | About 1 hour |
| Machine Dimension | 3000×1500×1750mm (L×W×H) |
| Working Footprint | 3500×5000mm (L×W) |
| Core Drive System | Multi-axis full servo motor system (main motor/embossing/feeding/storage/edge traction) |
| Standard Core Systems | Intelligent web guiding system, intelligent anti-curvature system, high-precision register system, automatic counting system, edge material automatic winding mechanism |
| Certification | EU CE Certification |
Aluminum foil, composite film, coated paper, PP/PE film, sealing gasket, easy-tear film, easy-peel film and other common food packaging rolls
Target Customers: Food packaging manufacturers, dairy processing plants, fast food packaging factories, customized packaging processing enterprises, foreign trade export-oriented packaging enterprises
Dayuan Intelligent Manufacturing has established a standardized, global factory-direct after-sales service management system. Backed by 28 years of R&D and manufacturing experience in paper packaging equipment, we have built a senior technical service team covering machinery, electrical engineering and production processes, providing one-stop full-process services including installation & commissioning, operation training, fault response, spare parts supply and upgrade & iteration for customers in over 80 countries and regions worldwide. Guided by our core philosophy of Your Profit, Our Mission, we go beyond ensuring stable equipment operation, and empower customers to reduce costs and increase efficiency through full-life-cycle services, so as to deliver the long-term profitable value of the equipment.
The whole machine is covered by a 12-month free warranty, and core servo drive components are covered by an 18-month free warranty.
All orders are delivered on-site by factory-certified engineers, who complete equipment positioning and installation, horizontal accuracy calibration, no-load operation test and full-load production commissioning, ensuring that the equipment reaches the factory-standard capacity, accuracy and operational stability upon delivery, and helping customers quickly enter mass production and profitability.
We provide systematic hands-on training for the customer's operation team on site, covering four core modules: basic equipment operation, daily maintenance, common fault troubleshooting and basic process adjustment. Adopting a theory-practice combined teaching mode, we ensure that trainees can independently complete routine production, daily operation and maintenance, and basic problem solving, reducing dependence on senior technicians.
A dual-track response mechanism of remote diagnosis + on-site service is established. Equipped with a digital remote service system, we can quickly troubleshoot conventional program and electrical faults. If on-site handling is required, certified engineers will arrive at the site at the first time to minimize downtime and production losses for customers.
Original spare parts for all series of equipment are stably supplied for a long time. Relying on a standardized warehousing system, common wearing parts and core functional parts are kept in stock with stable supply and efficient delivery.
We provide software updates for equipment control systems to continuously optimize equipment performance and the user experience.
The actual service scope for industrial equipment is affected by multiple factors, including but not limited to: basic industrial supporting conditions in different countries and regions, differences in power and environmental standards, transportation and logistics accessibility at the customer’s factory location, professional competence and operational standardization level of the customer’s on-site operators, customized configurations at the time of purchase (such as number of printing units, special functional modules, customized process adaptation, etc.), actual operating conditions, daily maintenance level and life cycle stage of the equipment. Therefore, this policy is for reference only. The final service scope, response time, warranty terms and cost provisions shall be subject to the formal business contract signed by both parties.
A: This machine is mainly used for automatic die cutting of yogurt cup lids, aluminum foil sealing lids, composite film cup lids, easy-tear sealing gaskets and easy-peel films, widely used in the packaging production of dairy, beverage and food industries.
A: The CC450-S adopts five-linkage die cutting structure, with a maximum punching speed of 450 strokes per minute. The actual production speed may vary slightly according to the processing material and mold structure.
A: Equipped with multi-axis full servo control system, the die cutting positioning accuracy is stable at ±0.15mm, producing cup lids with burr-free and indentation-free edges and high consistency.
A: It can adapt to various common food packaging materials, including 35-150μm aluminum foil, 60-250g/m² paper and 10-300μm film, covering the production needs of most cup lids and sealing films.
A: The equipment adopts quick-change mold design, the whole set of mold replacement time is only about 1 hour. At the same time, parameters can be saved/called with one click, making order change and debugging convenient.
A: Yes, the CC450-S cup lid die cutting machine has obtained EU CE certification, is designed and manufactured in accordance with international high standards, and is exported to more than 80 countries and regions worldwide.
A: It is standard equipped with three intelligent systems: intelligent web guiding, intelligent anti-curvature and high-precision register tracking. It also has automatic counting, edge material automatic winding and vacuum adsorption anti-drop functions, reducing manual intervention throughout the process.
|
