Modular Timber Beam Formwork Lightweight Formwork For High Rise Building

Categories Timber Beam Formwork
Brand Name: WKS
Certification: ROHS
Place of Origin: Hebei,China
MOQ: 50 piece
Price: US $5.90 - 6.80/ Square Meter
Payment Terms: T/T
Supply Ability: 1000 piece in 10 days
Delivery Time: 10-30 workday
Packaging Details: Bundled / Tied in bundles/Optimization of container loading
Product name: Timber Beam Formwork
Material: Flange :spruce/fir wood , Web:poplar plywood
Wood type: Finland Spruce/fir&plywood
Bending Bearing Moment: 11KN M
Shear Capacity (broken loading): 24KN
web thickness: 27mm or 30mm
Color: yellow
Width: 8cm
Height: 20cm
Length: 900mm-5900mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Modular Timber Beam Formwork Lightweight Formwork For High Rise Building

H20 Timber Beam Formwork High Rise Building Slab and Shear Wall
Product Overview

The H20 Timber Beam Formwork is a high-strength, engineered wood I-beam system designed for slab, wall, and column construction. Combining solid timber flanges with a plywood web, it delivers the ideal balance of lightweight handling and industrial load capacity, making it a cost-effective choice for residential and commercial projects.

Features & Functions
  • High Load-to-Weight Ratio: Engineered I-beam design provides exceptional bending strength (approx. 5 kNm) and shear resistance, supporting heavy wet concrete with minimal deflection.
  • Lightweight & Manual Handling: Weighing only ~5 kg/m, it allows for crane-free installation by a small crew, significantly reducing equipment and labor costs compared to steel systems.
  • All-Weather Durability: Treated with waterproof yellow paint and fitted with protective end caps to resist moisture absorption and mechanical damage, ensuring longevity on site.
  • Modular Flexibility: Standard 200mm depth beams are compatible with global formwork systems (Doka, Peri, etc.), allowing versatile configurations for complex layouts and reusability across multiple projects.
Key Specifications
  • Beam Dimension: 200mm (H) x 80mm (W)
  • Construction: Solid Spruce/Pine flanges + 27mm Plywood Web
  • Standard Lengths: 1.45m to 6.0m (custom lengths available)
  • Adhesive: WBP/Phenolic (Weather & Boil Proof)
  • Max Reuse Cycles: 30-50+ cycles with proper care
Technical Specifications
ProductH20 Timber Beam
Wood TypeFinland Spruce/Fir & Plywood
ColorYellow
Width8cm
Height20cm
Length900mm - 5900mm
WeightApproximately 4.5kg - 30kg
MaterialsFlange: Spruce/Fir Wood, Web: Poplar Plywood
Wood Moisture12% ± 3% at delivery
Surface ProtectionWaterproofed using water-repellent color glaze
Flange WallWidth: 80mm, Thickness: 40mm
Web Thickness27mm or 30mm
Shear Capacity24KN (broken loading)
Bending Bearing Moment11KN*M
Application Scope

Residential & commercial buildings, concrete tanks, basements, bridge abutments and piers, irregular concrete structures, and various engineering projects including buildings, water conservancy, hydropower, bridges, culverts, and high-rise structures.

H20 Timber Beam formwork system in use
Competitive Advantages
  • Lowest Initial Investment: Offers the most economical entry point for contractors needing a reliable, high-capacity formwork system without the high cost of metal alternatives.
  • Eco-Friendly & Sustainable: Made from renewable timber resources with a lower carbon footprint than steel or aluminum, appealing to green building standards.
  • Proven Global Standard: The H20 specification is universally recognized, ensuring easy integration, spare part availability, and reliable performance on job sites worldwide.
  • Experienced engineering team with average working experience of 10+ years
  • Over 20 years of production experience ensuring stable product quality
  • Factory located in industrial cluster area providing significant cost advantages
  • Full cycle project services to ensure smooth application of H20 timber beam formwork
One-Stop Solution Service Process
  • Free Consultation Service: Provide construction drawings for evaluation of cost-effective formwork system solutions with detailed quotation
  • Full Process Project Team Service: Dedicated team for professional engineering solutions, business communication, and on-site construction management
  • Project Emergency Plan Service: Comprehensive planning including emergency handling procedures for formwork system products
Frequently Asked Questions
  • Are you a trading company or a manufacturer?
    We are a subsidiary foreign trade company of a group company, responsible for exporting formwork and scaffolding products. Our group has two major production bases with over 20 years of production experience.
  • What services do you provide?
    We provide professional implementation solutions, high-quality products, and efficient technical support services in the field of templates and scaffolding.
  • Do you provide samples? Are samples chargeable?
    Yes, we provide samples. Customers pay for shipping costs.
  • What information is needed for design and quotation?
    Architectural and structural drawings of the project are required.
  • How to get a quotation?
    For simple projects with your own engineer, provide bill of materials. For complex projects like apartments and residences, provide engineering drawings for our engineers to develop application plans and quotations.
  • How long for design and quotation after providing drawings?
    Typically 5-8 days to complete specific plans and detailed quotations.
  • What is the delivery time after contract signing?
    Usually 20-30 days for stocking, depending on project complexity. More accurate timelines provided during planning.
  • What are your payment terms?
    T/T: 30% deposit before manufacture, 70% balance against B/L copy. Or L/C.
H20 Timber Beam manufacturing and quality control process
