High Speed Rotary Screen Printing Machine Semi Automatic Multi
Color Screen Printer
This high-speed multi-color rotary semi-automatic screen printing
machine with servo control is specifically engineered for
cylindrical container printing. Compatible with plastic, glass,
metal, and various other materials, it features intelligent PLC
control with a high-performance touch screen interface.
Advanced Control System
Equipped with German LEUZE sensors for precise multi-color
registration, the machine utilizes servo control for vertical
movement, left-right screen movement (Wecon system with adjustable
stroke), and tube rotation (Wecon system, gear-free). Combined with
a variable speed device, this creates a highly stable drive system
with excellent synchronization and automatic positioning
capabilities.
Key Features
- Exceptional flexibility with fast and easy fixture changes
- Same main body structure with only fixture replacement required
- High precision printing with exquisite results
- Brand-new drive system ensuring high stability and synchronization
Technical Specifications
| Item | Specification | Brand | Origin |
|---|
| 1. Touch Screen | 7 inch | Wecon | China |
| 2. PLC | 3SA-30MT | Wecon | China |
| 3. Vertical Servo Motor | 750W | Wecon | China |
| 4. Left-Right Screen Servo Motor | 750W | Wecon | China |
| 5. Rotation Servo Motor | 750W | Wecon | China |
| 6. Positioning Sensor | -- | LEUZE | Germany |
| 7. Linear Guide | HGW15CC | HIWIN | Taiwan, China |
| 8. Solenoid Valve | DC24V | AirTAC | Taiwan, China |
| 9. Air Pressure | 4-6 KG | -- | -- |
| 10. Power | 220V 50-60Hz 3KW / 3000W | -- | -- |
| 11. Printing Speed | 800-1000 pcs/h (1-color)
600-800 pcs/h (multi-color) | -- | -- |
| 12. Printing Diameter | Ø15-120 mm | -- | -- |
| 13. Machine Size | L850 * W900 * H1600 mm | -- | -- |
| 14. Machine Weight | 260 kg | -- | -- |
About Dongguan Hao'an Printing Machinery Co., Ltd.
Established in 2016, Dongguan Hao'an Printing Machinery Co., Ltd.
is a professional manufacturer of automated printing equipment. Our
product range includes silk screen printing machines, transfer
printing machines, stamping machines, and peripheral equipment
designed to meet printing requirements for various shapes and
materials.
Our machinery is widely used across multiple industries including
cosmetics, daily necessities, food, medical supplies, and
automotive accessories. We export to numerous countries and regions
including Europe, the United States, South Korea, the Middle East,
South Africa, and Mexico, earning high trust from domestic and
international customers.
We adhere to five core concepts: efficiency, excellence, energy
conservation, integrity, and win-win cooperation. Our strong
professional R&D team can customize machinery according to
specific customer requirements and continuously innovate to make
products more intelligent and efficient. Beyond providing excellent
equipment, we offer professional technical training and
comprehensive support services.
Packaging and Shipping
Frequently Asked Questions
Q. How long is the machine's warranty period?
A. We offer a 2-year warranty and long-term service
Q. What technical support services are provided after purchase?
A. We provide on-site installation service and professional
engineer training
Q. How will you help us resolve after-sales repair issues if the
machine malfunctions?
A. In case of machine malfunction, we will provide video and email
communication, and on-site service is available if necessary
Q. What inks does the machine support?
A. We use UV-based environmentally friendly inks, imported
environmentally friendly inks
Q. What certifications can you provide?
A. We have ISO9001, SGS, and RoHS certifications
