Customized 470μH I-shaped Power Inductor with Vertical Direct Insertion for Compact PCB Design

Customized I-shaped Inductor 10 * 16-470uH Direct Insertion I-shaped Vertical Power Inductor

1.Product Description

This customized 10 × 16mm vertical I-shaped power inductor adopts a direct insertion structure, providing a high inductance value of up to 470 μ H. The I-shaped magnetic core structure design optimizes the magnetic circuit efficiency, balancing excellent DC superposition characteristics with lower magnetic core losses. The vertical installation method effectively saves PCB board area and is suitable for high-density power supply layouts. It is widely used in DC-DC converters, power filters, energy storage, and various high current power circuits, and is a reliable component choice for improving power supply stability and efficiency.

1. High sensitivity and compact design: Within a compact volume of only 10mm diameter x 16mm height, a high sensitivity value of up to 470 μ H has been achieved, providing an ideal choice for high-power density power supply design.

2. Vertical direct insertion structure: It adopts vertical installation (vertical) and direct insertion pins, which not only ensures firm soldering and strong resistance to mechanical stress, but also greatly saves the lateral board area of the PCB, which is conducive to optimizing the layout of the circuit board.

3. Excellent power and stability: As a power inductor, its I-shaped magnetic core structure has good anti saturation characteristics and can withstand large DC bias currents, ensuring high efficiency and stability in high current applications such as power conversion and filtering.

4. High reliability: The sturdy magnetic core and enameled wire winding process ensure the long-term reliability and long service life of the product in complex working environments such as high temperature and high vibration.

In summary, it is a reliable inductive component with a compact vertical structure that achieves high inductance and high power, optimized for space saving and high-performance direct insertion power circuits.
