Modular steel garage /warehouse/barnDesign Common Norms
"Steel Design Code" (GB50017-2003)
"Cold-formed steel structure technical specifications"
(GB50018-2002)
"Construction Quality Acceptance of Steel" (GB50205-2001)
"Technical Specification for welded steel structure" (JGJ81-2002,
J218-2002)
"Technical Specification for Steel Structures of Tall Buildings"
(JGJ99-98)
Component and Characteristics of the Construction
The main frame (columns and beams) is made of H section steel,
steel grade is Q235 or Q345
The envelop construction net is made of cold form C-style purlin
The wall and roof are made of color steel board or sandwich panels
Prefab Steel Structure Metallic Workshop/WarehouseSteel structure building is widely used as workshop, warehouse,
factory, prefabricated house, hotel, church, garage, etc. It is
durable, economic and environmentally friendly.
Steel Structure Workshop:
1) Different sizes:
MOQ is 100m2, width X length X eave height.
2) Different types:
Single slope;
double slope;
Sing span;
double-span;
Multi-span;
single floor, double floors.
3) Different Bases:
Cement and steel foundation bolts.
4) Different Columns and Beams:
Material Q345(S355JR) or Q235(S235JR) steel, all bolt connections,
Straight cross-section or Variable cross-section.
5) Different bracings:
X-type or V-type or other type bracing made from angle, round pipe,
etc.
6) Different Purlins:
C or Z type: Size from C120~C320, Z100~Z200.
7) Different Roof and Wall Panel:
Single colorful corrugated steel sheet 0.326~0.8mm thick, (1150mm
wide) or sandwich panel with EPS, ROCK WOOL, PU insulation
thickness around 50mm~100mm.
8) All accessories:
Semi-transparent skylight belts, Ventilators, down pipe, Galvanized
gutter, etc.
9) Surface:
Two lays of Anti-Rust Paint.
10) Packing:
Main steel frame without packing load in 40'OT, roof and wall panel
load in 40'HQ.
You ONLY need you to provide us with the following information:
Design Parameters:
1) Live load on roof (KN/M2);
2) Wind speed (KM/H);
3) Snow load (KG/M2) - If Applicable;
4) Earthquake load - If Applicable;
5) Style of Doors and Windows;
6) Crane (if you have), Crane span, Crane lift height, max lift
capacity, max wheel pressure and min wheel pressure;
7) Size: width X length X eave height, roof slope;
8) Or your idea!
BUT maybe you are unsure about what type or what needs you have
regarding you're warehouse/workshop, or this project is your first
one. Don't worry, we will teach you to choose the right style and
the finest design within your budget.
Generally speaking,our Steel structure warehouse/workshop are
categorized as below:
(1) Simple Steel Structure Workshop
|
| Main structure | Single span: L -shorter than 18m, H -lower than 6m |
| Maintenance system | Roof | Colored steel sheet with 50mm glass wool insulation |
| Wall | Colored steel sheet |
| Door | Simple steel rolling shutter (within 10m2) |
| Window | Very few |
| Usage | Warehouse, workshop |
| Standard and suitable market | Africa, Middle-East, South America (no snow, wind load below
0.4kn/m2) |
|
(2) Standard Steel Structure Workshop
|
| Main structure | Single span: L -shorter than 24m, H -lower than 8m |
| Maintenance system | Roof | Colored steel sheet with 50mm glass wool insulation |
| Wall | Colored steel sheet or 50mm EPS sandwich board |
| Door | Wind resistance rolling door(within 15m2) |
| Window | Alu. Alloy (can use with skylight) |
| Usage | Warehouse, workshop, shopping mall, exhibition hall, super market |
| Standard and suitable market | Snow loading below 0.5kn,wind loading below 0.5kn/m2 |
|
(4) Cold Region (heavy snow) Steel Structure Workshop
|
| Main structure | Single span: L -shorter than 18m, H -lower than 6m |
| Maintenance system | Roof | EPS/rock wool/PU sandwich board |
| Wall | EPS/rock wool/PU sandwich board |
| Door | PU foamed rolling door |
| Window | Alu. Alloy, Hollow glass |
| Usage | Warehouse, workshop, shopping mall, exhibition hall, super market |
| Standard and suitable market | Cold regions such as Norway, Russian, North Canada, Finland,
Iceland, Greenland, Sweden, etc. (snow loads below 3kn, wind load
below 1KN/M2) |
|
(5) Steel Structure Workshop with Crane (5T, 10T, 20T)
|
| Main structure | Single span: L -shorter than 20m, H -lower than 10m |
| Maintenance system | Roof | Colored steel sheet with 50mm glass wool insulation |
| Wall | Colored steel sheet or sandwich board |
| Door | Wind resistance rolling door (within 15m2) |
| Window | Alu. Alloy (can use with skylight) |
| Usage | Warehouse, workshop |
| Standard and suitable market | Snow 0.5kn, wind load below 0.5kn/m2 |
|
2. Expansion-friendly
Sometimes clients have told us that they intend to extend their
building in future years as their business grows. With steel
buildings, this can actually be a very simple process. If the
original building was properly erected and well-maintained, you can
easily expand it rather than constructing an entirely new
structure.
3. Strong/Durable
We always like to highlight the superior strength and durability of
steel over other building materials. Warehouses often are used for
commercial and industrial spaces, meaning that they contain heavy
objects or heavy machinery that if mishandled can cause significant
structural damage. Steel buildings are better able to withstand
this type of impact damage.
4. Resistant to the Elements
Another strength of steel buildings is that they can handle a wide
range of environments and climates. They are extremely fire
resistant, which makes them the perfect choice if your warehouse
stores combustible materials. Furthermore, they are also grounded
buildings, and if struck by lightning, can safely disperse the
charge into the earth. Steel building are also built with wind
exposure in mind to ensure your building will withstand the various
wind exposure it will encounter.
5. Energy Efficient
Energy efficiency is one of the primary concerns of any business
owner. You want to make sure that the building is affordable as
possible in the future. With steel buildings, it is often important
to insulate your building for proper temperature control. Nothing
can hurt the efficiency and affordability of a building worse than
super-high heating or cooling bills. Lucky for you, metal is
reflective, and therefore can reflect heat, making buildings less
warm in the hot, sunny months. Another reason metal buildings and
roofs can stay cooler is due to the addition of chemicals designed
to reflect infrared wavelengths, which can be added to the metal
building paint.
6. Customizable Exterior
Steel buildings are easily customizable in their appearance, and
can be designed to fit a certain local or a specific company brand.
From eaves to massive garage doors to skylights, we can make sure
that your building has the look pictured in your head.
.
|
C or Z purlin
| Size: C100--C320,Z160--Z300.
|
Roof and wall panel
| Single layer galvanized color steel sheet, thickness: 0.3-0.6mm
|
Color steel sandwich panel: EPS, Glasswool,Rock wool,PU insulation
panel
|
insulation thickness:50mm, 75mm,100mm, insulation panel width:
900mm
|
Accessories
| Semi-transparent skylight belts,ventilators,down pipe,gutter,etc.
|
Surface
| Painting or hot dip galvanized.
|
Application
| Permanent & temporary residence,office,workshop,warehouse,etc.
|
Characteristic
| Various dimension,lower cost,easy installation and favorable
insulation.
|
Design
| According to your construction drawing or we design as per your
detailed demand.
|
Fabrication
| Strictly fabricate as per the drawings confirmed.
|
Transportation
| Good relationship with many vessel companies to make sure the
transportation
smooth.
|
Installation
| Carports/garages are easy to be installesd. Detailed construction
drawing will be offered for installation.
|
Bearing
| The common light prefabricated steel structure building can stand
heavy wind by
100km/h and 7grade earthquake.
|
Protection
| Color steel sandwich panel performs favorable fire proofing and
heat insulation.
|
Corrosion Resistance Prefabricated Steel Structure Warehouse Durable Cost Effective Solution
