Galvanized Welded Steel Grating with Serrated Surface for Platform Walkways

Platform Walkway Galvanized Welded Steel Grating
Steel bar grating is engineered for high strength and robust structural performance. Manufactured from carbon steel, aluminum, or stainless steel, it offers versatile solutions for various industrial applications. Available in multiple production types including welded bar, press-locked, swage-locked, and riveted grating, with surface options in both smooth and serrated designs.
Technical Specifications
Steel GradesLow carbon steel, mild steel, stainless steel or following customer requirements
Steel StandardsASTM A36, A1011, A569, AS3679, BS4360, GB700-88, Q235B, S235JR, S275JR, SS304L, SS316L etc.
Bearing Bar Specifications
  • Flat bars: 15x2, 20x3 to 100x10, 150x16mm etc.
  • I bars: 25x5x3, 32x5x3, 38x5x3, 40x5x3, 50x5x3, 50x7x4, 55x7x4, 60x7x4, 65x7x4, 70x7x4, 75x7x4mm, or customized
  • USA types: 1" x 3/16", 1 1/4" x 3/16", 1 1/2" x 3/16", 1" x 1/4", 1 1/4" x 1/4", 1 1/2" x 1/4", 1" x 1/8", 1 1/4" x 1/8", 1 1/2" x 1/8" etc.
Bearing Bar TypesPlain/Smooth, Serrated/Teeth, I Bar, Serrated I Bar
Bearing Bar Pitch12.5, 15, 20, 22, 23.85, 25, 30, 30.16, 30.3, 30.45, 31, 32.5, 33, 34.3, 35, 38, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm etc., or customized
USA types: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Cross Bar Pitch30, 38, 40, 50, 60, 76, 100, 101.6, 110, 120mm etc., or customized
USA types: 4", 3", 2" etc.
Grating TypesPress welded/webforge/electroforge grating, press locked grating, swage grating etc.
Hot Dip Galvanizing StandardsASTM A123, AS1650, BS729-1971, GB/T13912 etc.
Surface TreatmentNature/mill finish, hot DIP galvanizing, painting, spraying coating or following customer requirements
Production Standards
  • China: YB/T4001.1-2007
  • USA: ANSI/NAAMM(MBG531-88)
  • UK: BS4592-1987
  • Australia: AS1657-1985
  • JIS
Key Features
Anti-rust
Durable
Strong
Safe
Easy Installation
Product Characteristics
  • Designed to withstand repeated load impacts with outstanding durability
  • Large open area provides excellent drainage function and maintains hygiene
  • Easy to install and clean for low maintenance requirements
  • Corrosion resistant after galvanizing for long-term economy
  • Wide variety of types available for different application requirements
Packaging
Wrapped with film and straps on steel pallet packing or packed according to customer requirements.
