| Brand Name: | DAXIAN |
| Model Number: | DX8332A |
| Certification: | ISO9001,CE |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,,In cash |
| Supply Ability: | 30 sets per month |
| Delivery Time: | 30 days after order confirmed |
| Packaging Details: | Wooden case |
| Machine name: | Cable Halogen Acid Gas Content Testing Machine Tester |
| Standards: | IEC60754‐1 |
| Applicable: | Cable and wire |
| Material: | Fused quartz tube |
| Air flow meter: | 20mL~200mL adjustable |
| Power supply: | 220V, 60HZ,10A |
| Sampling: | 500mg~1000mg |
| Warranty: | 12 months |
| Company Info. |
| DONGGUAN DAXIAN INSTRUMENT EQUIPMENT CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
IEC60754‐1 Halogen Acid Gas Release Measurement Tester for Cable
Meets the standards:
It conforms to the standards of GB/T17650.1-1998, GB/T17650.2-1998 and IEC60754‐1:1994, IEC60754‐2:1991; it also satisfies the GB/T19666‐2005 “General Rules for Flame Retardant and Fire-resistant Wire and Cable”. Table 6 regulations and GA306.1-2007 Section 6.3.4, GA306.2-2007 Section 6.3.4, UL2556-2007 Sections 9.10 and 9.11 requirements.
Scope of application:
It is applicable to the determination of the total amount of halogen acid gas in low-halogen and halogen-free flame-retardant cables and the determination of the acidity of gases by measuring PH value and conductivity.
Equipment composition:
Specifications:
- Tubular furnace: The effective length and diameter of the heating chamber are 600×ф42mm, equipped with an adjustable electric heating system. Heating power: 220V /10KW
Combustion tube:
- Material: Refractory pipe made of silica, resistant to corrosive gas.
- Specifications: The inner diameter is 40mm, the length extending from the inlet side of the tube furnace is 60~200mm, and the length extending from the outlet side is 60~100mm, leaving a gap for thermal expansion.
Burning boat:
- Material: Use fused quartz tube.
- Specifications: length 100mm, width 25mm, depth 10mm.
- Combustion boat feeding method: using bar magnet and platinum wire pulling method.
Gas collection:
- Two selected bottles are used: one of which is equipped with a magnetic stirrer and contains 220 mL of sodium hydroxide solution.
Welcome to visit our factory for sightseeing!
