Automatic PLC Control Rubber Molding Press

Categories Rubber Vulcanizing Press Machine
Brand Name: SFC
Model Number: XLB-D1200x1200x1
Certification: CE, ISO
Place of Origin: china
MOQ: 1 set
Price: US$5,000.00-35,000.00
Payment Terms: T/T,L/C
Supply Ability: 60set/Month
Delivery Time: 25-35days
Packaging Details: Safety Wood or Plywood Crates Packing
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Automatic PLC Control Rubber Molding Press

Reliable Quality Rubber Molding Press / Rubber Vulcanizing Press
Product Overview
This high-performance rubber molding press features a two-way sliding mold vulcanizing system with large hot plate size and high working hydraulic pressure. Designed for producing large-scale rubber products with mold flexibility and high production efficiency.
Industrial rubber molding press machine with hydraulic system and control panel
Key Features
  • Two-way sliding mold vulcanizing system
  • Large hot plate size with high hydraulic pressure
  • Quick mold replacement capability
  • Multiple working layers for high production efficiency
  • PLC full automatic control system
  • Manual and automatic control modes
  • High-speed open/close mold operation
  • Compact structure with wide application range
Technical Specifications
Model: XLB-D1200x1200x1/3.15MN
Total Pressure: 3.15MN
Daylight: 150mm
Working Layers: 1
Piston Stroke: 150mm
Piston Diameter: 100mm
Weight: 7200kg
Voltage: 208/220/380/415/440/480V etc.
Production Capacity: 50 Sets/Month
Construction Details
Frame Plate: Q235 steel with shot blasting and zinc-rich lacquer coating
Hot Plate: 45# steel with normalization treatment and temperature control
Platforms: Q235 steel with precision welding and heat treatment
Cylinder: ZG270-500 with double seal structure
Sliding System: Hydraulic or mechanical sliding options
Control System: PLC full automatic control
Complete Model Range
ModelTotal Pressure (MN)Daylight (mm)Platen LayersUnit Pressure (MPa)Motor Power (KW)
XLB240*240*20.1512522.602.2
XLB350*350*20.2512522.042.2
XLB400*400*20.512523.132.2
XLB500*500*20.6312522.522.2
XLB600*600*21.001252-42.772.2
XLB700*700*21.2020022.452.2
XLB750*850*2/41.602002-42.513
XLB-Q900*900*22.0030022.475.5
XLB-DQ1200*1200*23.1520022.193
Quality Certifications: ISO9001:2008, SGS, CE Certified
Customer Services
  • Custom machine design and engineering support
  • Production progress tracking with photo updates
  • Complete documentation package
  • Free technical drawings and manuals
  • Overseas engineer service and operator training
  • 24-hour pressure testing and quality assurance
Rubber vulcanizing press operational view showing control interface
