| Categories | Thin Film Transistor |
|---|---|
| Brand Name: | ORIENTRONIC |
| Place of Origin: | China |
| MOQ: | First purchase, no purchase quantity limit. |
| Price: | Prices are set based on design and quantity. |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, Paypal |
| Supply Ability: | 200K Sets / Month |
| Delivery Time: | 4~6 Working Days |
| Packaging Details: | Prices are set based on design and quantity. |
| Size: | 3.5-inch TFT |
| Resolution: | 320XRGB X 480. The display orientation can be adjusted, either in landscape or portrait mode |
| Touch IC: | GT911 |
| Touch type: | 5-point capacitive touch. Capacitive touch. It can simultaneously identify the real-time accurate positions, movement trajectories and touch areas of 5 touch points |
| Module size: | Capacitive touch: 55.26 (W) X 84.52 (H) X 5.48 (T) mm |
| Display area: | 48.96 (W) X 73.44 (H) mm |
| Display driving chip: | ST7796 |
| Interface type: | Screen interface: 8-bit (8-bit parallel port), touch part: IIC interface |
| Pixel size: | 0.153 X 0.153 |
| Backlight type: | LED X 6 |
| Voltage: | 3.3V |
| Current: | 90ma |
| Pin count: | 20 pins, 2.54 (mm) spacing, double row pins |
| Viewing angle direction: | 12 o'clock direction |
| Operating temperature: | -20~70 degrees |
| Company Info. |
| Shenzhen Orientronic Display Electronic Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| Pin Number | Pin Name | Function Description |
| 1 | VCC | Positive power supply 3.3V |
| 2 | GND | Power ground pin |
| 3 | BLK | Backlight control switch. The backlight is enabled by default and turned off with a low level |
| 4 | RES | LCD reset for the display section |
| 5 | CS | LCD select signal for the display section, valid with a low level |
| 6 | WR | LCD data/command selection pin for the display section |
| 7 | RD | Serial port write control pin |
| 8 | R0 | Serial port read control pin |
| 9-16 | D0-D7 | 8-bit data line |
| 17 | CRES | Reset pin for the touch chip, the pin is connected to pin 4 (RES) through a 0-ohm resistor R7 by default: select one of them; simultaneous reset is sufficient |
| 18 | CINT | Touch interrupt |
| 19 | CSCL | IIC communication clock for the touch section |
| 20 | CSDA | IIC communication data line for the touch section |
|
