Liquid Cooling System Copper High-Density Fin Heat Sink

Material: Copper 1020
Product dimension: 70x70x9mm
Product weight: 0.089 kg
Feature: Reliable performance and durable in material
Surface treatment: passivation
Heat conducting power: 30W
Product Technology: Skiving + passivation

Skiving fin heat sink

Skiving fin is the process of relieving Al teeth. The profile is processed into a specific model, such as radiator, etc. with the skiving fin machine tool, the finished product is the skiving fin heat sink.

The skiving fin heat sink is a kind of gap structure with the same sequence formed by cutting the material out of a certain angle by mechanical action of the strip profile (aluminum and copper). It is used to solve the heat dissipation of high-power devices under the condition of air cooling and heat dissipation, and its heat dissipation efficiency can be increased by 8-15% compared with the other heat sink.

With the large-scale application, our skiving fin radiator technology are more mature, the level of automation is gradually improved, our cost and reliability advantages are remarkable. It is used in UPS, base station, charging pile, frequency converter, controller, wind power converter, SVG, LED lamp.

Application Fields

100G/200G pluggable optical modules for data center switches
Small optical modules for fronthaul/mid-haul equipment of 5G base stations
Low-power optical communication components for edge computing nodes

Manufacturing Capabilities

Advanced Brazing Technology

Brass / Copper CNC

Aluminium / Zinc CNC

Stainless steel and steel CNC machining samples

Stainless Steel / Steel CNC

Plastic CNC

Key Applications

1.LED lighting
High-power LED street lights, factory lighting, stage lighting, and plant growth lights. Extruded heat sinks effectively manage the high heat generated by LED chips, extending the life of the lamp and maintaining stable light efficiency.
2.Power Electronics
In high-power density applications such as server power supplies, communication power modules, UPS (uninterruptible power supplies), industrial frequency converters, electric vehicle charging stations, and photovoltaic inverters, extruded heat sinks ensure that power semiconductor devices (such as IGBTs and MOSFETs) operate within a safe temperature range, preventing overheating and failure.
3.Industrial control and automation
Industrial PCs, programmable logic controllers (PLCs), servo drives, and robot controllers. In harsh industrial environments, extruded heat sinks provide reliable heat dissipation for sensitive electronic components, ensuring long-term stable operation of the equipment.
4.Telecommunications
5G base stations, routers, network switches, and data center servers. As data transmission rates increase, the heat generated by communication equipment increases dramatically. Extruded heat sinks provide an efficient passive cooling solution to reduce operating costs.
5.Consumer Electronics
High-performance desktop CPU/GPU cooling, game consoles, home theater systems, and large-screen TVs. In consumer electronics products that pursue extreme performance and compact design, customized extruded heat sinks can optimize heat dissipation efficiency and enhance user experience.
6.New Energy Vehicles
Power battery management system (BMS), motor controller, and onboard charger. New energy vehicles have extremely high heat dissipation requirements. Extruded heat sinks are key components that ensure stable operation of the power system under various driving conditions.

Production Equipment

Our air-cooled equipment includes: 10 units of low-temperature solder reflow ovens, 5 units of baking ovens, 20 units of automatic solder dispensing equipment, 3 units of automatic solder brushing equipment, 50 units of torque-controlled electric screwdrivers, 1 unit of CCD inspection equipment, 2 units of fully automatic optical module testing equipment, 11 units of multi-station thermal performance testing equipment, 4 units of flatness optical testing equipment, and other related equipment.

Production facility with automated manufacturing equipment

Quality Assurance

We maintain rigorous quality standards with 1 Coordinate Measuring Machine, 1 projector instrument, 2 water high pressure testing machines, 4 thermal resistance testing machines, and 2 liquid leakage testing machines.

Company quality certifications for cooling plate manufacturing

Customer Service

Prompt response to all inquiries
Competitive pricing with guaranteed quality
Efficient production scheduling
Optimal transportation solutions
Comprehensive technical support

Frequently Asked Questions

Are you a trading company or manufacturer?

We are a professional manufacturer of heat sinks and water cooling plates with extensive experience and a strong technical team, featuring automated and mechanized production.

Have you exported goods before and to which regions?

60% of our total production is exported to Japan, India, UK, Canada, USA, and Brazil.

How many employees do you have?

Approximately 100 employees across sales, purchasing, engineering, QA, warehouse, and production departments.

Can you provide samples if we agree with the design?

Yes, we provide samples for confirmation before mass production, along with technical drawings if required.

What packing methods do you use?

Customized packing with normal cartons and tight-proof fabric or wooden cartons for optimal protection during transportation.

Do you provide technical support for product issues?

All products are fully inspected before shipping. For any issues, we provide immediate technical solutions.

Product Tags:


*From:	Your email address is incorrect!
*To:	Guangdong Uchi Electronics Co.,Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Liquid Cooling Plate
Brand Name:	Uchi
Model Number:	Aluminum Heat Sink
Certification:	ISO9001:2015 ISO9001:14001
Place of Origin:	Dongguan，Guangdong,China
MOQ:	100pcs
Price:	Negotiable
Payment Terms:	T/T，paypal， Western Union,MoneyGram
Supply Ability:	50000000pcs per Month
Heat conducting power:	30W
fan life:	50000 Hrs
material:	Copper 1020
Size:	70x70x9mm
Weight:	0.089 kg
Surface treatment:	passivationHeat conducting
Feature:	Reliable performance and durable in material
