| Brand Name: | SGI-GRAPHITES |
| Place of Origin: | shanghai |
| Price: | negotiable |
| Model Number: | Customized products without models |
| Certification: | ISO , CE |
| MOQ: | 10pcs |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs per day |
| Delivery Time: | 10-25 working day |
| Packaging Details: | wodden cartons or meet customers' requirements |
| Application: | Smart phones, table PCs, LED |
| Chemical Composition: | 99.9%C |
| UL flammability rating: | 94VO |
| Temperature resistance: | - 40℃ to 400℃ |
| Thermal resistance: | 450℃ |
| Conductivity: | 19000s/cm3 |
| Company Info. |
| SGI-GRAPHITES |
| View Contact Details |
| Product List |
High Purity Carbon Fiber Made Flexible Graphite Carbon Paper Roll
Synthetic graphite is a material consisting of graphitic carbon which has been obtained by graphitizing of non-graphitic carbon, by CVD from hydrocarbons at temperatures above 2500 K, by decomposition of thermally unstable carbides or by crystallizing from metal melts supersaturated with carbon
| Thickness (mm) | DSN5012 | DSN5017 | DSN5025 | DSN5032 | DSN5040 | DSN5050 | |
| 0.012±0.003 | 0.017±0.003 | 0.025±0.003 | 0.032±0.004 | 0.04±0.005 | 0.05±0.05 | ||
| Thermal conductivity | X-Y axis (w/m.k) | 1700~1900 | 1500~1700 | 1400~1600 | 1300~1500 | 1200~1400 | 1100~1300 |
Z axis (w/m.k) | 15~18 | 15~18 | 16~19 | 17~20 | 18~20 | 18~21 | |
| Density (g/cm3) | >2.05 | >2.05 | >2 | 1.8~1.9 | 1.75~1.85 | 1.65~1.75 | |
| Hardness(shore A) | 85 | 85 | 85 | 85 | 85 | 85 | |
| Tensile strength (psi) | 650 | 650 | 650 | 650 | 650 | 650 | |
| Heat resistance temperature (℃) | 400 | 400 | 400 | 400 | 400 | 400 | |
| Thermal resistance (℃) | 0.15% | 0.15% | 0.15% | 0.15% | 0.15% | 0.15% | |
| Electric conductivity (s/cm) | 19000 | 19000 | 19000 | 19000 | 19000 | 19000 | |

|
