300V M19 10 Pin Wire To Board Power Connector Quick Lock Waterproof Plug Socket

300V M19 10 Pin Wire To Board Power Connector Quick Lock Waterproof Plug Socket

300V M19 10 Pin Wire To Board Power Connector Quick Lock Waterproof Plug Socket
300V M19 10 Pin Wire To Board Power Connector Quick Lock Waterproof Plug Socket
Categories Waterproof Data Connector
Brand Name: Ulinkcon
Model Number: M19
Certification: CE/Rohs/TUV/UL
Place of Origin: China
MOQ: Negotiation
Price: Negotiation
Payment Terms: T/T,D/P,L/C,D/A,Western Union,MoneyGram
Supply Ability: 100000 pairs Montly
Delivery Time: 3~6working days
Packaging Details: 1.Plastic bag;2.Carton;3.As per customer's requirements
Pin: 10Pin
Material: Nylon
Current rating: 5A
Gender: Male to Female
Type: Plug/Socket
Contact Material: Brass Gold-Plated
Contact Now
Company Info.
Shenzhen Ulinkcon Technology Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

300V M19 10 Pin Wire To Board Power Connector Quick Lock Waterproof Plug Socket

300V M19 10 Pin Wire To Board Power Connector Quick Lock Waterproof Plug Socket
Product Overview

M19 10 Pin Waterproof Quick Disconnect Wire To Board Connectors

Key Specifications
  • Electrical Specifications: Rated voltage 300V DC/AC, 10Pin configuration, single Pin rated current 5A (suitable for multi-circuit parallel power supply), supporting stable power transmission and meeting industrial medium and low voltage power supply standards
  • Structural Specifications: M19 standard circular structure, conforming to industrial universal interface dimensions, compatible with wire diameter range 18-26AWG, supporting Wire To Board connection mode, male-female pairing design, suitable for panel mounting and cable docking
  • Environment & Service Life: Operating temperature range -40℃~+105℃, resistant to extreme high and low temperature environments; mechanical mating life ≥1500 cycles, meeting long-term repeated operation and maintenance needs
  • Applications: Industrial automation control equipment, outdoor LED display power supply, new energy industrial facilities, marine electrical systems, heavy machinery control panels, outdoor sensor arrays, medical equipment (portable diagnostic instruments) and other Wire To Board power transmission scenarios requiring high reliability, waterproof and dustproof, and quick connection
Electrical Parameters
Number of Poles10Pin
Current Rating5A max.
Voltage Rating300VAC max
Durability Voltage1500VAC @ 60 s.
Application Industries
  • Growth Lights
  • Communications Application
  • Product Coding Machines
  • Inventory Product Coding
  • Inkjet Systems
  • Solar System
  • Industrial Inkjet Equipment
  • Electric Power Equipment
  • Laboratory Forensic & Pathology Equipment
  • Communications Equipment
  • Heavy Machinery
Technical Parameters
Contact Resistance10 mΩ max
Insulation Structure500 MΩ at 500VDC
Operating Temperature-40°C ~ +105°C
IP ClassIP67 (1m / 30min) when mated
Mold MaterialPA66
Contact/Terminal MaterialGold Plated Brass
Seal MaterialSilicone
Main Features
  • Push lock quick release system
  • Multic-core options: 2Pin, 3Pin, 4Pin, 5Pin for Power
  • 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin for power signal combined
  • 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin for signal available
  • Field assembly version: both wire to wire and wire to board options
  • Cable assembly service supported, welcome to custom
  • OEM/ODM welcome
Operation Parameters
Voltage Rating300VAC max
Current Rating5A max
Min Wire Size OD3.0mm ~ 6.0mm
Max Wire Size OD8.0mm ~ 10.0mm
Max. Cable Cross Section Area0.5mm² ~ 2.5mm²
Design Sketch
M19 10 Pin Waterproof Connector Design Diagram M19 10 Pin Connector Technical Specifications and Dimensions
Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
Q: How can I get samples?
A: It's my honor to offer you samples, and the freight should be paid by yourself. You can let me know your courier number and your detail address, then I can send you sample at once.
Q: What shipping methods do you offer? How long is the delivery time?
A: We provide multiple shipping options: 1) Courier (DHL/UPS/FedEx): 3 - 7 working days for small parcels; 2) Air freight: 7 - 15 working days; 3) Sea freight: 20 - 45 working days. Delivery time varies by destination and shipping method.
Shipping and Logistics Information
