| Certification: | ISO9001:2015, ISO14001:2015, IATF16949, UL/cUL, ROHS, REACH, CQC |
| Pitch: | 2.54mm (0.1 inch) |
| Model Number: | MTDPR-08-V |
| Number of Positions: | 8 Position (8 Bit) |
| MOQ: | 1000pcs |
| Delivery Time: | 3~4 Weeks |
| Circuit Function: | SPST, ON-OFF |
| Packing: | Anti-static Tube Packing |
| Payment Terms: | T/T |
| Contact Plating: | Gold-plated Copper Alloy |
| Price: | US$0.05-0.18 |
| Housing / Actuator Color: | Red Housing with White Actuator |
| Supply Ability: | 1,000,000pcs/month |
| Compliance: | RoHS Compliant |
| Brand Name: | Chipsen |
| Product Type: | Piano Type DIP Switch / PCB Code Switch |
| Packaging Details: | Carton 1: 25.5 X 21.5 X 21cm. Carton 2: 43.5 x 24.5 x 21 cm |
| Customization: | OEM / ODM Available (Position, Color, Marking) |
| Place of Origin: | China |
| Terminal Type: | Right Angle Through Hole |
| Company Info. |
| Dongguan Chipsen Electronics Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
The MTDPR-08-V is an 8 position piano type DIP switch built on a 2.54mm (0.1") pitch footprint with right angle through hole terminals. Each of the 8 independent SPST ON-OFF circuits is actuated by a white side-lever key on a red flame-retardant housing, so operators can set an address, baud rate, or configuration code from the edge of the board — after the PCB is already mounted inside the enclosure.
Compared with a standard flat slide DIP switch, the piano (side-actuated) format keeps the operating face parallel to the front panel, which shortens assembly time and removes the need for a service technician to open the top cover. The part is RoHS compliant, supplied in anti-static tube packing, and is available for OEM / ODM customization in position count, housing color, and terminal plating.
| Model No. | MTDPR-08-V |
|---|---|
| Switch Type | Piano Type DIP Switch (side-lever actuator) |
| Number of Positions | 8 Position (8 bit) |
| Circuit / Function | SPST, ON-OFF, per position |
| Pitch | 2.54 mm (0.100 inch) |
| Terminal / Mounting | Right Angle Through Hole (PCB / DIP mount) |
| Housing Color | Red housing / white actuator (other colors on request) |
| Contact / Terminal Plating | Gold-plated copper alloy |
| Contact Rating | 25 mA / 24 V DC switching or other |
| Contact Resistance | ≤ 50 mΩ or other |
| Insulation Resistance | ≥ 100 MΩ @ 500 V DC or other |
| Operating Life | 2,000 cycles or other |
| Operating Temperature | -25°C ~ +70°C |
| Compliance | RoHS |
| Packing | Anti-static tube packing |
| Place of Origin | China |
A standard DIP switch is actuated from the top of the package. A piano type DIP switch uses side-mounted lever keys, so it is operated from the edge of the PCB. This lets you change settings through a front panel slot without removing the board or opening the top cover.
Each position is an independent SPST ON-OFF circuit, so 8 positions provide 2⁸ = 256 binary combinations — enough for device addressing, baud rate selection, or mode configuration on a single component.
The terminals are on the standard 2.54mm (0.1") grid used by mainstream DIP switch land patterns. Send us your footprint drawing or the competitor part number and we will confirm dimensional compatibility before you order.
Yes. The MTDPR series supports OEM / ODM changes to position count, housing color, actuator color, terminal plating and marking. Share your specification and we will quote the tooling and unit price.
Yes, the MTDPR-08-V is RoHS compliant. Compliance documentation and test reports can be issued with the shipment on request.
Samples are available for evaluation. MOQ and lead time depend on quantity and whether customization is required — contact us with your target volume and we will reply with a firm schedule.
Send us your position count, terminal form and target quantity — we will reply with a quotation and 2D drawing within 24 hours.
|
