♦ Large Scale Tomato Grading Fruit Potato Shrimp Onion Weight Checker Machinery Frozen Fish Fillet Weight Sorting Machine

I. Product introduction
Belt weight sorting machine is mainly applied to the automatic weighing of product classification. Namely separate the weight grades according to the setting of the product specification. Each product is weighed separately and automatically reject to the specified weight grade or weight category. Efficiently replace the manual sorting, increase the product standardization and sorting speed. Reduce the error of manual operation, which is widely used in aquatic products, seafood, poultry, medicinal materials, hardware, plastic products, chemical raw materials etc.
II. Features
1.Waterproof and moisture-proof structure design. Operate well in
high humidity and harsh environment.
2.100 sets of product parameters seting and stored. And can be
freely switched according to the using requirements.
3. High precision weighing module and stable control system.
4. Flapper rejector sorting: 3 million life testing.
5. Quantity of sorting grades: no limit, at present we have done 26
weight stations
6. Weighing data output:RS232/485, USB interface, wireless data
transmission, local area network station
management platform, cloud platform.
| Model | WYZF-400*150 | WYZF-400*200 | WYZF-600*200 | WYZF-700*200 | WYZF-700*300 | WYZF-800*200 |
| Weighing capacity | 200g | 500g | 5000g | 5000g | 5000g | 5000g |
| Weighing accuracy | ±0.3g | ±0.5g | ±3g | ±5g | ±10g | ±10g |
| Weighing speed | 120pcs/min | |||||
| Sorting grades | no limit (more than 2 grades) | |||||
| Weighing belt size (mm) | L400*W150 | L400*W200 | L600*W200 | L700*W200 | L700*W300 | L800*W200 |
| Applicable product size(mm) | L200*W120 | L200*W150 | L400*W150 | L500*W150 | L500*W250 | L600*W150 |
Weighing direction | Left to right or right to left depending on the customer's site. | |||||
| Weighing sensor | Original Germany HBM | |||||
| Operation display | 8 inches touch screen | |||||
| Belt conveyor | Food grade PU belt | |||||
| Height of conveyor | Customized according to the usting needs | |||||
| Power supply | Single phase AC220-240V,50/60HZ(Customized) | |||||
| Construction | SUS304,polishina Waterproof and moisture-proof structure | |||||













|
