| Categories | Motor Test System |
|---|---|
| Weight: | 25 kg |
| Model Number: | SXDJ |
| Operating temperature: | -10°C to 50°C |
| MOQ: | 1 |
| Software compatibility: | Windows OS |
| Brand Name: | Sansion |
| Power Capacity: | Supports motor testing up to 10000 kW |
| Delivery Time: | 30 work days |
| Max capacity: | <1000KN |
| Packaging Details: | plywood case |
| Power supply: | AC 220V/50Hz |
| Certification: | CE SGS ISO9001 |
| Voltage Class: | 0 – 10 kV |
| Payment Terms: | T/T,L/C |
| Power Consumption: | ≤180kW under full load |
| Place of Origin: | China |
| Company Info. |
| Sansion Power Electric Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
The Multi-Function Electric Motor Comprehensive Test Bench is an all-in-one solution for companies that want to perform multiple motor tests using a centralized platform.
The system integrates power supply, measurement instruments, loading equipment, sensors, control cabinet, data acquisition hardware and testing software to provide a complete motor testing solution.
It can be used for factory acceptance testing, R&D, quality control, maintenance inspection and product performance verification.
| Test Category | Typical Testing Items |
|---|---|
| Electrical Performance | Voltage, current, power, power factor, frequency |
| Mechanical Performance | Torque, speed, output power |
| Efficiency | Input/output power and efficiency |
| No-Load Test | No-load current, speed, loss |
| Load Test | Torque, speed, power and efficiency under load |
| Thermal Test | Temperature and temperature rise |
| Insulation Test | Insulation resistance |
| Safety Test | Power frequency withstand voltage |
| Starting Test | Starting performance and starting torque |
| Locked-Rotor Test | Locked-rotor current and torque |
| Mechanical Condition | Vibration and noise |
| Data Management | Data acquisition, storage, curve generation and reporting |
What is the difference between a motor tester and a motor comprehensive test bench?
A: A basic motor tester may focus on one or several parameters. A comprehensive test bench integrates electrical, mechanical, thermal and safety-related testing into a more complete platform.
Can this system be used for both R&D and production testing?
A: Yes. The configuration can be optimized for laboratory performance testing, product development, factory quality inspection or EOL testing.
Can customers specify their own testing standards?
A: Yes. The test sequence, measurement parameters and acceptance criteria can be configured according to applicable standards and customer requirements.
|
