| Categories | Wire Mesh Machine |
|---|---|
| Model Number: | field fence machine |
| MOQ: | 1pcs |
| Delivery Time: | 15-18days |
| Brand Name: | Qijie |
| Packaging Details: | wood case, steel pallet |
| Payment Terms: | L/C, T/T |
| Name: | Automatic Field Fixed Knot Cattle /Deer Grassland |
| Price: | Discuss |
| Max Length of Roll: | 100m |
| Supply Ability: | 15pcs |
| Material: | steel |
| Certification: | sgs |
| wire gauge: | 2.5mm-3.0mm |
| Place of Origin: | China |
| Company Info. |
| Hebei Qijie Wire Mesh MFG Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Automatic Weaving Netting Cattle Fence Wire Mesh Making Machine
NAME | GRASSLAND FIELD FENCE MACHINE |
Machine Type | grassland fence machine |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | New Product 2025 |
Warranty of core components | 1 Year |
Core Components | PLC, Engine, Bearing, Gearbox, Motor, Gear |
Wire Diameter (mm) | 1mm - 2.5mm |
Production Capacity | 85times/min |
Place of Origin | TIANJIN,China |
Brand Name | XHH |
Model Number | XHH-2000 |
Weight (KG) | 2000 |
Power (kW) | 7KW |
Key Selling Points | Low Noise Level |
Warranty | 1 Year |
Applicable Industries | Hotels, Garment Shops, Building Material Shops, Machinery Repair
Shops, Retail, Food Shop, Printing Shops, Construction works ,
Advertising Company |
Showroom Location | Morocco, South Korea, Chile, Algeria, Sri Lanka, Romania,
Bangladesh, Kazakhstan, Nigeria, Uzbekistan, Tajikistan, Malaysia,
Egypt, Turkey, Italy, Viet Nam, Brazil, Peru, Saudi Arabia,
Indonesia, Pakistan, Mexico, Russia, Thailand |
Product name | grassland fence machine |
weaving width | 2000mm |
weaving wire diameter | 2.0-4.0mm |
capacity | 1.5T/ton |
Color | blue |
Voltage | 380v |
Mesh Size | 83-254mm |
weight | 3.2T |
machine dimension | 3500x3500x2700mm |
power | 10kw |
Roll mesh collection system.
Roll mesh collection system will automatically adjust the tightness
according to the roll mesh diameter,It's more convenient to
take away the roll mesh.
Wire mesh weaving system.
All parts of the weaving system are made of special alloy materials
with high hardness, which increases the service life of the parts.
Cross wire feeding system.
The cross wire enters from the side of the machine, which can
clearly separate the horizontal wire from the vertical wire, the
machine runs more smoothly.
Wire cutting system.
The structure of the shearing system is specially designed to
complete the shearing process quickly and efficiently and increase
the product output.
Machine control system.
The control system is composed of Chinese and English,the spacing
of the cross wires can be adjusted on the touch screen.
Cross wire straightening device.
Each cross wire is straightened twice horizontally and vertically
to ensure the flatness of the wire mesh.
Motor.
The whole machine uses high-performance motors with different
powers in different positions to minimize the power consumption in
production and use.
Field Fence Making Machine Main features
1 Field Fence Making Machine is developed after many years our
company has independent intellectual property rights, self-made.
2.Field Fence Making Machine uses sophisticated computer control,
advanced production technology.New style Technology upgrade hinge
joint Field Fence Making Machine grassland fence machine
3.With novelty, high degree of automation, operational safety and
reliability, easy operation, long life and low prices
4.Product neat and beautiful,diverse specifications
5.The warp holes can be crimped and no crimped.
|
