| Categories | Nickel Based Alloy |
|---|---|
| Model Number: | GH2132 |
| MOQ: | 5tons |
| Delivery Time: | 15-45 days, depending on the situation and quantity |
| Packaging Details: | Bending, Welding, Decoiling, Punching, Cutting and Others. |
| Payment Terms: | L/C,D/A,D/P,T/T |
| Brand Name: | TsingShan |
| Place of Origin: | Fujian，China |
| Price: | Negotiable |
| Supply Ability: | 100000 Tons/Year |
| Certification: | ISO9001、ISO14001 |
| Company Info. |
| Shanghai Tsingtuo Metal Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Nickel‑based alloys are high‑performance special metallic materials with nickel as the matrix. By adding alloying elements such as chromium, molybdenum, copper, niobium and tungsten, they acquire excellent comprehensive properties: resistance to strong acid and alkali corrosion, chloride‑ion pitting corrosion, crevice corrosion and stress‑corrosion cracking, together with high‑temperature strength, oxidation resistance, as well as favorable welding and processing performance.
Our company supplies corrosion‑resistant nickel‑based alloys and nickel‑based superalloys, including N08825, N10276, N02200, N02201, N04400, GH3625, GH4169 and GH2132. These products are widely used under extreme working conditions such as chemical industry, flue‑gas desulfurization, offshore engineering, caustic‑soda manufacturing, aero‑engine components and high‑purity electronic pipelines. Forms available include plates, coiled plates, bars and tubes.
Product parameters
| Parameter | Specification |
| Material | N08825 (Incoloy 825)；N10276 (Hastelloy C-276)；N02200 (Nickel 200)；N02201 (Nickel 201)； N04400 (Monel 400)；GH3625 (Inconel 625)；GH4169 (Inconel 718)；GH2132 (A-286) |
| Product Form | Plate, Coil, Bar, Seamless Pipe, Welded Pipe |
| Plate / Coil | Cold-rolled: Thickness 0.3~6.0 mm, Width 1000~1500 mm, Length
2000~6000 mm Hot-rolled: Thickness 3.0~50 mm, Width 1000~2500 mm, Length 2000~6000 mm Medium plate: Thickness 50~100 mm, Width 1000~3000 mm, Length customizable |
| Bar | Round bar: Diameter φ6~300 mm (cold-drawn/hot-rolled/forged),
Length 3000~6000 mm, max. 12000 mm Hex/Square bar: Across flats 6~80 mm Flat steel: Thickness 10~100 mm, Width 30~300 mm |
| Seamless Pipe | Outer diameter φ6~273 mm, Wall thickness 0.5~30 mm, Single length ≤12000 mm (Small-diameter precision tube: OD down to φ4 mm, wall thickness 0.5~3 mm) |
| Welded Pipe | Outer diameter φ6~630 mm, Wall thickness 1.0~10 mm, Fixed length 6000~12000 mm |
| Surface Finish | Cold-rolled plate: 2B, BA, No.4, 8K；Hot-rolled plate: No.1；Bar: Black, Peeled (PEEL), Ground (PD), Polished；Pipe: Pickled, Bright annealed (BA) |
| Applicable Standards | GB/T 14992 series + ASTM B series + AMS + JIS G4901/4902 + EN 2.4 series |
| Certifications | ISO 9001, ISO 14001 |
Chemical Composition
| GB | JIS | ASTM | EN | Chemical Composition (Mass Fraction /%) | Other Elements | |||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu | N | |||||
| 05Cr21Ni42Mo3Cu2Ti | NCF825 | N08825 | 2.4858 | 0.050 | 0.50 | 1.00 | 0.020 | 0.030 | 38.00~46.00 | 19.50~23.50 | 2.50~3.50 | 1.50~3.00 | - | Fe≥22.0, Ti: 0.60~1.20, Al≤0.20 |
| 00Cr16Ni57Mo16W4 | NW0276 | N10276 | 2.4819 | 0.010 | 0.08 | 1.00 | 0.025 | 0.010 | allowance | 14.50~16.50 | 15.00~17.00 | - | - | Fe: 4.00~7.00, W: 3.00~4.50, Co≤2.50, V≤0.35 |
| N6 | NW2200 | N02200 | 2.4066 | 0.15 | 0.35 | 0.35 | - | 0.010 | ≥99.0 | - | - | 0.25 | - | Fe≤0.40 |
| N4 | NW2201 | N02201 | 2.4068 | 0.02 | 0.35 | 0.35 | - | 0.010 | ≥99.0 | - | - | 0.25 | - | Fe≤0.40 |
| Ni68Cu28Fe | NW4400 | N04400 | 2.4360 | 0.30 | 0.50 | 2.00 | - | 0.024 | ≥63.0 | - | - | 28.00~34.00 | - | Fe≤2.50 |
| GH3625 | NCF625 | N06625 | 2.4856 | 0.10 | 0.50 | 0.50 | 0.015 | 0.015 | ≥58.0 | 20.00~23.00 | 8.00~10.00 | 0.50 | - | Nb+Ta: 3.15~4.15, Fe≤5.00, Al≤0.40, Ti≤0.40, Co≤1.00 |
| GH4169 | NCF718 | N07718 | 2.4668 | 0.08 | 0.35 | 0.35 | 0.015 | 0.015 | 50.00~55.00 | 17.00~21.00 | 2.80~3.30 | 0.30 | - | Nb+Ta: 4.75~5.50, Al: 0.20~0.80, Ti: 0.65~1.15, Feallowance, Co≤1.00, B: 0.002~0.006 |
| GH2132 | SUH660 | S66286 | 1.4980 | 0.08 | 1.00 | 1.00~2.00 | 0.030 | 0.020 | 24.00~27.00 | 13.50~16.00 | 1.00~1.50 | - | - | Ti: 1.90~2.35, Al: 0.10~0.50, V: 0.10~0.50, Feallowance, B: 0.001~0.010 |
FAQ
Q1: Are you factory or trader?
A1: Tsingtuo Metal Technology is a manufacturer of stainless steel
since 2023. We've gained our export right and become an integrated
company of industry and trade in order to satisfy buyers'
multi‑requests on different materials and products.
Q2: Which material/products you can provide?
A2: Ferritic stainless steel/Low nickel stainless steel/Stainless
steel clad plate/Precipitation‑hardening stainless steel/Nickel
based alloy/Austenitic stainless steel/Martensitic stainless
steel/Duplex stainless steel are available.
Q3: How to get a sample?
A3: Free samples are available for your checking and testing. And
to get free samples, you need to send us your detailed receiving
address (including post code) and your DHL/FedEx/UPS account for
sample collection; the courier cost will be on your side.
Q4: Can you produce the products according to my own drawings?
A4: Yes, we can produce the products according to your drawings
that will best satisfy you.
Q5: How to visit your factory?
A5: Most of the main cities have flights to Shanghai; you can take
a flight to Shanghai Pudong/Hongqiao International Airport.
If you come from Hong Kong, it will take 2 hours by flight, with
around 5 flights every day around noon time.
|
