8000 - 9000 Bottles/Hour Automatic Labeling Machine Different Conveyor Systems Bottle Labelling Machine

Categories Automatic Labeling Machine
Label Speed: 20-50bottles/min
Certification: VERIFICATION OF CONFORMITY
Speed: 254mm/sec
MOQ: 1 set
Applicable Label Range: length 10 ~ 260mm, width 10-155mm
Operator: 1 set/person
Capacity: 8000-9000 bottles per hour
Place of Origin: CHINA
Safetyfeatures: Emergency stop button, safety guards
Model Number: ZRD-220
Price: Negotiable
Name: Automatic Labeling Machine
Brand Name: ZHIROBO
Delivery Time: 15-30 working days
Payment Terms: T/T
Feature: High Stability
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

8000 - 9000 Bottles/Hour Automatic Labeling Machine Different Conveyor Systems Bottle Labelling Machine

Automatic Labeling Machine ZRD-220
Basic Use

Mainly used for laser coding and rewinding of various coiled materials.

Equipment Advantages
  • Human-machine interface with microcomputer programmable control.
  • Equipped with three-servo control system. Servo motors control rewinding and unwinding tension to ensure stable and reliable material tension; servo positioning film feeding with adjustable length.
  • Adopts high-precision water-cooled ultraviolet laser.
  • Adjustable coding quantity for products.
  • Easy operation, automatic fault alarm and one-key intelligent operation.

Equipment Layout

Main Technical Parameters
ModelZRD-220 Rewinding Coding Machine
Material Width50-220mm
Material DiameterMax outer diameter: 245mm (core diameter: 76mm)
Coding SpeedDepends on coding requirements
Mechanical Allowable Speed0-30m/min
Laser Type10W UV Laser (355nm)
Voltage and PowerAC220V 2.6KW
Air Pressure0.5mpa
Machine Dimensions1620mm*1380mm*1750mm
Net Weight1600KG
Configuration Parameters
ModelRewinding Coding Machine ZRD-220
Touch ScreenHMI
Servo Roll FeedHCFA
Roll Feeding DriverHCFA
Fixed-length ServoHCFA
Fixed-length DriverHCFA
Rewinding ServoHCFA
Rewinding DriverHCFA
Laser Coding MachineKEXIN
Laser Galvo ScannerKEXIN
ReducerSmart
Detection FiberKEYENCE
PLCHCFA
Air SwitchCHINT
Switching Power SupplyMEAN WELL
Deviation CorrectionYoudao
RelayIDEC
Push Button SwitchSchneider
CylinderXINGCHEN
FilterSTNC
Solenoid ValveSTNC
Magnetic SwitchAirTAC
BearingNSK
FrameImported Powder Coating
Motion ControllerHCFA
Photoelectric SensorBoyee
Guide RailHIWIN
