Weather‑Resistant 160W Solar Power Panel, Series‑Parallel Supported For Custom Solar Array

Categories	Common Solar Panel
Model Number:	JST-EWMH-(160-170)W
Dimensions:	1105×765×30mm
Power Tolerance:	0~+4.99W
Mechanical Load:	Front 5400Pa / Rear 2400Pa
MOQ:	1
Packaging Details:	1105×765×30mm
Current at Pmax:	8.00A-8.39A
Maximum System Voltage:	700Vdc
Price:	based on quantity
Open Circuit Voltage:	23.18V-23.34V
Max Series Fuse:	10A
Supply Ability:	2000 pcs/month
Module Efficiency:	18.93%-20.11%
Place of Origin:	China
Short-Circuit Current:	8.43A-8.82A
Maximum Power:	160W-170W
Voltage at Pmax:	19.99V-20.26V
Brand Name:	KUOMAN
Weight:	9.11kg

Contact Now

Add to Cart

Company Info.

KUOMAN INDUSTRY LIMITED

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Weather‑Resistant 160W Solar Power Panel, Series‑Parallel Supported For Custom Solar Array

Product Highlights

Our (160‑170)W monocrystalline PV panel adopts premium 182mm 66‑cell solar cells, delivering stable rated power from 160W up to 170W with high‑efficiency up to 20.11%. Manufactured with durable 3.2‑mm tempered glass and sturdy aluminum frame, this compact‑size solar module works reliably under harsh outdoor conditions. It is a versatile off‑grid power solution perfect for residential, camping, RV and remote‑area power supply.

Key Specifications

Electrical Characteristics	160W	170W	Mechanical Specifications
Maximum Power (Pmax)	160W	170W	External Dimensions: 110576530mm
Open Circuit Voltage (Voc)	23.18V	23.34V	Weight: 9.11kg
Short-Circuit Current (Isc)	8.43A	8.82A	Solar Cells: Monocrystalline 18260.66mm (417pcs)
Voltage at Pmax (Vmp)	19.99V	20.26V	Front Glass: 3.2mm Tempered Glass
Current at Pmax (Imp)	8.00A	8.39A	Frame: Anodized Aluminum
Module Efficiency (ηm)	18.93%	20.11%	Junction Box: IP67
Power Tolerance	0~+4.99W	0~+4.99W	Output Cables: 90cm (customizable)
Maximum System Voltage	700Vdc (IEC/UL)	700Vdc (IEC/UL)	Connector: MC4 Compatible
Max Series Fuse Rating	10A	10A	Mechanical Load: Front 5400Pa / Rear 2400Pa

Key Advantages

Unmatched Efficiency: 20.11% module efficiency (170W model) generates more power per square meter than competing 160-170W panels.
700V System Ready: Supports large-scale series connections for utility-grade or industrial off-grid systems.
Built to Endure: IP67 junction box, 3.2mm tempered glass, and 5400Pa wind/snow load resistance ensure decades of reliable performance.
Scalable Design: Customizable cable lengths and MC4 compatibility simplify integration into complex PV arrays.

Frequently Asked Questions

Q: Can this panel charge a 24V battery?

A: Yes! The Vmp (19.99-20.26V) is ideal for 24V battery systems (with a compatible charge controller).

Q: How many panels fit on one pallet?

A: 36 panels per pallet (dimensions: 1155*1130*885mm; weight: 325kg).

Q: Is it suitable for coastal areas?

A: Absolutely. The IP67 junction box and corrosion-resistant aluminum frame withstand salt, moisture, and extreme weather.

Application Scenarios

Large Off-Grid Homes: Primary power for remote cabins, farms, or eco-resorts.
Commercial Rooftops: Small businesses, warehouses, or agricultural facilities seeking energy independence.
Telecom & Utilities: Powers remote cell towers, weather stations, or grid-tied backup systems.
Mobile Applications: Heavy-duty RV solar systems, large boats, or mobile command centers.

Packing Configuration

Module Dimensions: 1105*765*30mm
Pallet Dimensions: 1155*1130*885mm
Pallet Weight: 325kg
Pieces per Pallet: 36
