| Categories | GF Piping System |
|---|---|
| Product Type: | Relay Module |
| Model Number: | 3-9900.393 |
| Maximum Switching Voltage: | 250 VAC |
| Price: | USD 100-10000/Piece |
| Installation Method: | Plug-In Field Installable Module |
| Supply Ability: | 1/piece in stock |
| Product Model: | +GF+ Signet 3-9900.393 |
| Brand Name: | +GF+ |
| Maximum Switching Current: | 5 A |
| Payment Terms: | T/T |
| Number of Relays: | 2 Programmable Relays |
| MOQ: | 1 |
| Delivery Time: | 3-7 |
| Packaging Details: | 50*50*50mm |
| Compatible Device: | Signet 9900 Transmitter |
| Certification: | 3C |
| Relay Type: | Dual SPDT Dry-Contact Relays |
| Place of Origin: | America |
| Company Info. |
| Xiamen ZhiCheng Automation Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
The 3‑9900.393 is a field-installable plug-in Relay Module that adds two programmable SPDT dry-contact relays (5A @ 250VAC / 30VDC) to a panel-mount 9900‑1P base unit for pump/alarm switching.
It lets the 9900 directly drive high‑power AC/DC loads—dosing pumps, solenoid valves, and audible alarms—with adjustable hysteresis & time delay, removing the need for external interposing relays.
| Parameter | Specification |
|---|---|
| Product Type | Relay Module (Plug-in Module) |
| Model / MFR # | 3-9900.393 (Code: 159 001 698) |
| Relay Type / Quantity | Two (2) programmable dry-contact relays (SPDT) |
| Maximum Switching Voltage | 250 VAC / 30 VDC |
| Maximum Switching Current | 5 A (resistive load) |
| Power Supply | 10.8 – 35.2 VDC, 300 mA (from DC PWR terminals) |
| Installation Type | Panel Mount only |
| Compatible Base Unit | Signet 9900 Transmitter (Panel Mount version) |
| Indicator | Two red mechanical relay status LEDs on the 9900 front panel |
| Adjustable Parameters | Hysteresis and time delay for each relay |
