A two-roll calender is a forming machine composed of two parallel rollers rotating in opposite directions. Relying on the pressure and shear force generated at the roll gap, it compresses viscous materials such as rubber, plastic, silicone and graphite into continuous sheets or films with uniform thickness and smooth surfaces. Unlike the two-roll mixing mill (for rubber mixing and plasticating), its core function is precision thickness setting and sheet extrusion.
| Model | XY-2I 320 | XY-2I 630 | XY-2I 1120 | XY-2I 1500 | XY-2I 1830 | XY-2I 1730 |
|---|---|---|---|---|---|---|
| Roller Diameter (mm) | 160 | 230 | 360 | 450 | 550 | 610 |
| Roller Working Length (mm) | 320 | 630 | 1120 | 1500 | 1830 | 1730 |
| Speed Ratio | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 |
| Roller Linear Speed (r/mm) | 7:79 | 14.8 | 3-20.2 | 2.5-24.8 | 2-18.7 | 4-36 |
| Min. Thickness of Products (mm) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
| Products Width (mm) | 250 | 580 | 920 | 1250 | 1600 | 1500 |
| Main Motor Power (KW) | 5.5 | 15 | 37 | 45 | 75 | 90 |
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., LTD is located in Qingdao west coast new economic district, which is a high-tech enterprise "specializing and New" Enterprise, Nation "High-tech" Enterprise, etc. has been achieved, trademark "顺富昌" registered, and has passed ISO9001:2015 quality system certification, Swiss SGS certification and CE export certification. All the machines are designed with 3D software and are not only sold all over the country, but also exported to the United States, Britain, Russia, the Netherlands, Thailand, Malaysia, Indonesia, Chile, Mexico, Uzbekistan, France and many other countries and regions.
The main products of our company including new banbury mixer, rubber mixing mill, vulcanizing press, rubber calender, batch of cooler, rubber kneader, forced feeding straining extruder, new waste tire recycling line, reclaimed rubber equipment etc., and can design and manufacture various special rubber machinery according to customer requirements.
|
