| Categories | DC Brushless Motor |
|---|---|
| MOQ: | 2000 |
| Delivery Time: | 45days |
| RATED CURRENT: | 0.26A |
| MOTOR TYPE: | Brushless dc motor |
| Certification: | CE, RoHS |
| NO LOAD CURRENT: | 0.1A MAX |
| Model Number: | DH-B3650-04 |
| NO LOAD SPEED: | 1760RPM±10% |
| Payment Terms: | T/T |
| STALL TORQUE: | 69.9mNm |
| Price: | 10€ |
| RATED TORQUE: | 24.3mNm |
| Supply Ability: | 50000PCS/months |
| STALL CURRENT: | 1A |
| Brand Name: | DEHE MOTOR |
| RATED VOLT: | 24VDC |
| Place of Origin: | CHINA |
| RATED SPEED: | 1453RPM±10% |
| Packaging Details: | Cartoon Box |
| DRIVER: | Can be customized |
| Company Info. |
| Shenzhen Dehe Motor Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | ||||||||||||||||||||||||||||||||||||
| OPERATING RANGE | RATED | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | |||||||||||||||||||||||||||||||
| r/min | A | r/min | A | g.cm | W | g.cm | A | |||||||||||||||||||||||||||||||||
| DH-B3650-01 | 8V~16V | 12V | 4304 | 0.28 | 3486 | 1.197 | 211.2 | 7.586 | 1116.6 | 5.104 | ||||||||||||||||||||||||||||||
| DH-B3650-02 | 8V~26V | 18V | 6693 | 0.3 | 5555 | 1.552 | 305.9 | 17.43 | 1799.5 | 7.537 | ||||||||||||||||||||||||||||||
| DH-B3650-03 | 8V~26V | 24V | 8458 | 0.4 | 6851 | 1.794 | 395.2 | 27.77 | 2079.8 | 7.628 | ||||||||||||||||||||||||||||||
|
