Name: XIANDA Marble Basalt CNC Diamond Bead Wire Saw Stone Cutting Profiling Machine
Brand: Xianda Machinery
Price: 1 USD

Home > Used Tools >

XIANDA Marble Basalt CNC Diamond Bead Wire Saw Stone Cutting Profiling Machine

Categories	Diamond Wire Saw Machine
Cutting Precision:	High
Wire Diameter:	7.2-11mm
Model Number:	DTWS-1500
Main Motor:	15kw
Wire Length:	10m
Supply Ability:	1000 Sets/Year
Max Processing Size:	300030001500mm
Adjustment Distance:	450mm
Automation:	Automatic
MOQ:	1
Delivery Time:	15-30days
Gross Motor:	11kw
Trolley Size:	1500*2500mm
Table bearing weight:	20T
Payment Terms:	L/C， T/T， D/P，，Paypal ，， Others
Diameter:	7.2mm to 11mm
Transport Package:	Plastic Package, Suitable For Sea Transportation
Price:	To Be Negotiable
Water Consumption:	4m3/H
Wire Speed:	0-40m/S
Certification:	API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Spindle:	15KW
Model NO.:	CNC-2000/2500/3000
Control:	CNC
Place of Origin:	Jinjiang, Fujian, China
Warranty Time:	One Year
Packaging Details:	Plastic Package, Suitable for Sea Transportation
Name:	Diamond Wire Saw Machine
Advantage:	Multi Function With Good Quality And Price
Control Type:	CNC
Brand Name:	Xianda Machinery

Contact Now

Add to Cart

Company Info.

Fujian Xianda Machinery co.,ltd

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

XIANDA Marble Basalt CNC Diamond Bead Wire Saw Stone Cutting Profiling Machine

CNC Control Diamond Wire Saw Machine with High Cutting Precision and Four-Spindle Linkage for Stone Cutting. Diamond Wire Saw Machine is an advanced and reliable cutting solution for special shape stone. Designed with four-spindle linkage and diamond wire saw for accurate cutting with high precision and quality. Equipped with CNC control system for easy operation.

XIANDA CNC Diamond Bead Wire Saw Machine in operation

Technical Specifications

Model Number	DISCOVERY 4-2000	DISCOVERY 4-2500	DISCOVERY 4-3000	DISCOVERY 4-2500S	DISCOVERY 4-3000S
Control System	CNC	CNC	CNC	CNC	CNC
Certifications	API, CCC, SONCAP, GOST, ISO, CE, SGS	API, CCC, SONCAP, GOST, ISO, CE, SGS	API, CCC, SONCAP, GOST, ISO, CE, SGS	API, CCC, SONCAP, GOST, ISO, CE, SGS	API, CCC, SONCAP, GOST, ISO, CE, SGS
Trolly size	1500*2500mm	1500*2500mm	1500*2000mm	1500*2000	1500*2000
Gross Weight	7500kg	8000kg	8500kg	8000kg	8500kg
Outline Dimension	680063003800mm	780063003800mm	880063003800mm	780068004300mm	880068004300mm
Max Processing Size	200030001200mm	250030001200mm	300030001200mm	250030001500	300030001500
Water Consumption	3m³/h	3m³/h	3m³/h	3m³/h	3m³/h
Main Motor	15KW PM MOTOR	15KW PM MOTOR	15KW PM MOTOR	15KW PM MOTOR	15KW PM MOTOR
Table Bearing Weight	20T	20T	20T	20T	20T
Wire Speed	20-40m/s	20-40m/s	20-40m/s	20-40m/s	20-40m/s
Production Capacity	1000 Sets/Year	1000 Sets/Year	1000 Sets/Year	1000 Sets/Year	1000 Sets/Year
Origin	Fujian, China	Fujian, China	Fujian, China	Fujian, China	Fujian, China

Applications

DISCOVERY4-2000/2500/2500/2000S/2500S. CNC Diamond wire cutting machine (rope saw) has function: Cutting column slabs, semi circular slabs, English letters, and other diversified complicated special shapes. Materials include marble, granite, natural stone, etc.

Key Features

Heavy load bearing structure with four orbits on each upright column, adjusted balance by rollers, with less friction and higher precision
Left and right frame achieve synchronized lifting by steering equipment on upper frame with increased accuracy via lead screw and double nuts
Cantilever part with lead screw and pole adjusting guide wheel distance, CNC-controlled guide wheel rotation angle
Worktable running by lead screw and railway
Automatic wire break alarm system

Factory Strength

Modern factory manufacturing facility with stone cutting machinery

40+ years manufacturing experience in stone cutting machinery
Export to 60+ countries worldwide
Professional R&D team for CNC cutting equipment
Full OEM/ODM customization support
Complete production line & strict quality inspection
After-sales service & technical support globally

Our Team

Packaging & Shipping

Securely packed in specialized packaging material with bubble wrap or foam protection. Shipping options include ground, air, and international shipping. All shipments are tracked and insured for safe delivery.

Frequently Asked Questions

What materials can the four-spindle diamond wire saw machine cut?

It can cut granite, marble, quartz, artificial stone, and other hard stones.

What is the cutting precision of this CNC diamond wire saw?

High cutting precision up to ≤0.01mm, ensuring smooth and accurate cutting.

Do you support customized size and parameters?

Yes, we provide full OEM/ODM customization for table size, power, voltage and functions.

Can you export to Europe, USA, Middle East and Southeast Asia?

Yes, we have rich export experience and provide safe packaging and fast delivery.

What is the advantage of four-spindle linkage?

It improves cutting efficiency, stability and multi-angle processing capacity.
