Interior 4mm Aluminum 3D core panel

Categories Film
Model Number: 4mm NCP - FILM
Payment Terms: L/C
Price: 20-35 USD / SQM
Packaging Details: WOODEN or NORMAL PACKAGE
Place of Origin: China
MOQ: 50 SQM / PER COLOUR
Supply Ability: 3000 SQM PER DAY
Delivery Time: 10-15 WORKING DAYS
Brand Name: OEM/KINGWINS
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Interior 4mm Aluminum 3D core panel

The aluminum non-combustible panel is a lightweight, durable, and highly rigid aluminum decorative panel perfect for all uses in architecture, transportation, furniture, and landmark buildings. It works great for both exterior and interior wall walls or home decoration Our aluminum panels are 2.5 to 6.0 mm thick and consist of a non-combustible metal core laminated between two layers of different thicknesses of aluminum skin. It's reached the A2 fire level, passed ASTM-E84, EN13501, the AS1530 fire test, and got certified.

PARAMETERS

  • Our NCP (Aluminum Non-Combustible Panel) is a 4mm thick Aluminium Core Panel that is completely non-combustible and suitable for internal and external applications where a non-combustible facade solution is required. It also has got certificates from Australian Standards, European Standards, and US Standards.
  • Our NCP is made of high-quality aluminum and has an 'egg carton type’ aluminum core that separates the shell. Unlike other non-combustible and fireproof panels, we does not require the use of mineral core fillers to achieve fire resistance, so it is lighter in weight and has comparable or better structural strength.
  • During the manufacturing process, we precoat a 3-coat PVDF coating to the surface. And we offer a wide range of standard colors and can also provide customized coatings that match specific color requirements.
PRODUCT SPECIFICATION
ITEMDESCRIPTION
Product UsageFully non-combustible and suitable for external applications
MaterialAluminum alloy 5052, 3003,1100 etc.
Fire BehaviourA2 Fire Safety (EN 13501-1:2018)
Regular Size1250x2500mm,1550x3200mm
Standard Width1250 mm / 1550 mm
LengthMax 6000 mm
Overall ThicknessRegular thickness: 4.0 mm (2.5 - 6.0 mm available)
Top Aluminum Thickness0.5mm - 0.7mm
Weight4.54kg / ㎡ (in 4.0 mm thickness)
Surface TreatmentPVDF, FEVE, PE Anodizing, Spectrum etc
PVDF/FEVE ColorSolid color, Metallic color, Wood color, Stone color, Brush
Warranty15 years
Applicable Temperature-40℃ to 80℃
Non-Combustible TestAS 1530.1 / BS467 / EN13501 / ASTM E84
Packagewooden pallet,8 pallets / 20GP,16 pallets / 40GP
KEY BENEFITS
  • A Grade Fire Proof
  • Flatness
  • Weather Resistance
  • Recyclable
  • Various Color Choices Meeing All Clients'options
  • Robust Durability
  • Full Machinability
  • Coil-coating Using PVDF Paint for Superior Finish, Color Integrity, and Performance
CASE SHARE
