Modular Split Type Anode Water Tank Electrolytic Plate Washing Tank

The anode water tank is specialized metallurgical auxiliary equipment designed for lead and copper electrolytic refining production lines. Installed at the discharging end of anode plate arranging machines, it performs anode plate spray washing, plate cooling, and collects washing waste liquid and residual electrolyte. As key auxiliary equipment preceding the electrolytic working procedure, it features an arc-shaped tank structure with modular split segments for convenient ocean container shipment.

All split arc steel components undergo comprehensive manufacturing processes including welding, flaw detection, rust removal, and anti-corrosion primer painting in-factory. Complete tank assembly on-site is achieved through bolt connections. Manufactured by Lufeng Machinery in compliance with ISO9001 quality management system, this equipment supports non-standard customization according to customer plate dimensions, electrolytic cell parameters, and plant space requirements.

Widely applied in new and existing smelting projects including crude lead electrolysis, waste lead-acid battery secondary lead production, and copper electrolytic refining. Designed to perfectly match full production lines including anode casting machines and anode plate arranging machines.

• Modular Split-Type Structure: Designed for ocean export with multiple arc-shaped segments to optimize container space utilization, reduce logistics costs, and enable on-site bolt assembly without field welding to shorten project installation periods.
• Reliable Welding & Superior Anti-Corrosion: Main body welded with heavy steel plate, key welding seams pass flaw detection inspection, all components undergo sandblasting rust removal and industrial anti-corrosion primer coating to resist humid, corrosive electrolyte environments and extend equipment service life.
• Optimized Arc-Shaped Liquid Collection: Efficiently collects washing waste water and overflow electrolyte, prevents liquid splashing and overflow, maintains tidy workshop conditions, and reduces electrolyte material loss.
• High Flexibility for Customization: Tank radian, inner width, total length, mounting support positions, and bolt hole positions processed according to client actual working conditions, suitable for both new projects and old electrolysis workshop renovations.
• Seamless Equipment Integration: Directly connects with discharge station of anode plate arranging machines to receive arranged anode plates and complete plate washing and cooling, enabling complete process flow from anode casting to cell feeding.

Suitable for crude lead electrolytic refining production lines, waste lead-acid battery recycling secondary lead smelting projects, copper electrolytic refining production lines, and automation upgrades for old electrolysis workshops to add plate washing stations together with anode plate arranging machines.
